Sullair Industrial Air Compressor 7509B AC

CAUTION: Do not mix different types of lubricants. Mixing lubricants can cause malfunctions or compressor damage and will void the compressor’s warranty.

CAUTION: Contamination of compressor fluids with mineral oil or other fluids can cause foaming, filter plugging, or orifice line obstruction.

Sullair encourages its customers to participate in a fluid analysis program with the fluid suppliers. In some cases, the analysis results suggest a fluid change interval that differs from the User Manual. Contact a Sullair representative for details.

When performing a fluid change or topping off the fill, the proper level should be at half of the sight glass, with the machine off.

Mixing, changing, or adding other lubricants within the compressor unit may void the air-end warranty.

Change the compressor fluid using instructions shown in the Lubrication Guide.

Refer to Figure 3-1 for the fluid fill port location.

Sullair’s 4500P-7500 series compressors are filled and tested at the factory with Sullube lubricant.

Does the maintenance gauge show red with the compressor running full load?

Clean the air filter’s exterior housing.

Release the hold-down clips and remove the end cover.

Remove the air filter element by pulling it out of the housing.

Clean the housing interior with a damp cloth. DO NOT blow dirt out with compressed air.

Reassemble in the reverse order.

Sign off on the air filter replacement

Warning: This procedure requires trained personnel with PPE!

Regulator and solenoid valve(s) are protected by a strainer

Hex cap removed from the strainer

If the screen is damaged, the strainer assembly must be replaced (P/N 241772)

Sign off on the strainer cleaning

Warning: Relieve all pressure from the receiver tank and all compressor lines before starting.

Pressure relieved from the receiver tank and all compressor lines?

Loosen and remove the eight (8) hex head capscrews (M12 x 40mm) from the cover plate.

Lift the cover plate from the receiver tank.

Inspect the receiver tank for rust, contamination, or damage.

WS Controller indicates the need for replacement

FLUID FILTER ELEMENT REPLACEMENT

Filter canister removed with a wrench

Filter element disposed properly

NOTE: Dispose of fluids in accordance with applicable federal, state, and local regulations.

Light film of fluid applied to the element seal
