Sullair Air-Cooled Compressor 10B 30HP-251333-004 AC

- Check the fluid level in the sump. Should the level be low, simply add the necessary amount

- Observe the gauges and indicators to be sure they monitor the correct readings for that particular phase of operation

- Check on the overall compressor and gauges to assure that the compressor is running properly after it has warmed up

- Clean the return line strainer after the initial 50 hours of operation

- Clean the return line orifice after the initial 50 hours of operation;

Order separator element repair kit number 250034-112 for 25 and 30HP compressors and repair kit number 250034-114 for 40HP compressors.

Relieved all pressure from the sump tank and all compressor lines

Disconnected all piping connected to the sump cover to allow removal (return lines, service lines, etc.)

Loosened and removed the hex head capscrews from the cover plate

Lifted the cover plate from the sump

Scraped the old gasket material from the cover and flange on the sump. Ensured not to let the scraps fall in the sump

Installed the new gaskets; one on the sump tank the other on top of the element

Reinserted the separator element into the sump taking care not to dent it against the tank opening

Replace the fluid filter element

Replace your fluid filter element and the gasket under any of the following conditions, whichever occur first

Conditions for replacing fluid filter element

To replace fluid filter element:

Using a strap wrench, remove the old element and gasket

Apply a light film of fluid to the new gasket

Hand tighten new element until new gasket is seated in the gasket groove

Place a bright light inside the element to inspect for damage or leak holes. Concentrated light will shine through the element and disclose any holes

Inspect all gaskets and gasket contact surfaces of the housing. Should faulty gaskets be evident, correct the condition immediately

If the clean element is to be stored for later use, it must be stored in a clean container

After the element has been installed, inspect and tighten all air inlet connections prior to resuming operation

Sign off on the air filter element inspection

Clean exterior of air filter housing

Remove the air filter cover by loosening the wingnut securing the cover

Remove element and clean interior of housing using a damp cloth. DO NOT blow dirt out with compressed air

Reset the filter maintenance indicator

Sign off on the air filter element replacement
