Maintenance Plans for Starlab Microcentrifuge Model Microcentrifuge 24

Integrate maintenance plans directly into your work orders in MaintainX.

Microcentrifuge Cleaning

Check mark

Preparation

Check mark

Switch off the device and disconnect it from the mains/power line.

Check mark

Ensure no liquids can penetrate the inside of the housing.

Check mark

Cleaning Procedure

Check mark

Use a mild cleaning fluid to clean the accessible surfaces of the device and the accessories.

Check mark

Carry out the cleaning as described in the following chapter.

Check mark

Disinfecting/Decontamination Procedure

Check mark

Choose the disinfection method according to legal regulations and guidelines.

Check mark

Carry out the disinfection or decontamination as described in the following chapter.

Run this procedureArrow right

Device Cleaning

Check mark

Preparation

Check mark

Open the lid

Check mark

Switch the device off at the mains/power switch

Check mark

Disconnect the mains/power plug from the voltage supply

Check mark

Remove the rotor

Check mark

Cleaning Process

Check mark

Clean and disinfect all accessible surfaces on the device including the mains/power cord using a damp cloth and recommended cleaning agents

Check mark

Thoroughly clean the rubber seal of the rotor chamber with water

Check mark

Rub the dry rubber seal with glycerol or talcum powder to prevent it from becoming brittle

Run this procedureArrow right

Fuse Replacement

Check mark

Preparation

Check mark

Disconnect the mains/power plug

Check mark

Fuse Replacement Process

Check mark

Open the fuse holder

Check mark

Replace faulty fuses and reinsert the fuse holder

Check mark

Post Replacement Check

Check mark

Is the fuse holder securely closed?

Check mark

Is the mains/power plug reconnected?

Run this procedureArrow right

Rotor Lid Cleaning

Check mark

Prerequisites

Check mark

Ensure the following prerequisites are met

Check mark

Recommended Cleaning Agents

Check mark

Use one of the following cleaning agents

Check mark

Cleaning and Preparation

Check mark

Remove the sealing ring to thoroughly clean the groove below it

Check mark

Clean and disinfect the rotor lid using the recommended cleaning agents

Check mark

Rinse the rotor lid thoroughly with distilled water

Check mark

Moisten the new sealing ring with clean water

Run this procedureArrow right

Rotor Cleaning

Check mark

Inspection

Check mark

Inspect the rotor and accessories for damage and corrosion

Check mark

Are all rotors and accessories free from damage?

Check mark

Cleaning and Disinfection

Check mark

Clean and disinfect the rotors and accessories using the recommended cleaning agents

Check mark

Clean and disinfect the rotor bores using a bottle brush

Check mark

Rinse the rotors and accessories thoroughly with distilled water

Check mark

Rinse the rotor bores of fixed-angle rotors particularly thoroughly

Check mark

Drying

Run this procedureArrow right

Parts for Starlab Microcentrifuge Microcentrifuge 24

Access the parts list for your equipment in MaintainX.

Part Name
Part Number

PCR Tube 0.2 Ml 1/24

S8030-0014

Micro Test Tube 0.4 Ml 1/24

S8030-0015

Micro Test Tube 0.5 Ml 1/24

S8030-0013

Rotor Standard 24 At Aerosol-Tight, 24 X 1.5/2 Ml Tubes Incl. Aerosol-Tight Rotor Lid, Microcentrifuge 24

S8030-0010

Rotor Lid Standard 24 At Aerosol-Tight, Aluminum

S8030-0011

PCR Tube 0.2 Ml 1/24

S8030-0014

Micro Test Tube 0.4 Ml 1/24

S8030-0015

Micro Test Tube 0.5 Ml 1/24

S8030-0013

Rotor Standard 24 At Aerosol-Tight, 24 X 1.5/2 Ml Tubes Incl. Aerosol-Tight Rotor Lid, Microcentrifuge 24

S8030-0010

Rotor Lid Standard 24 At Aerosol-Tight, Aluminum

S8030-0011

PCR Tube 0.2 Ml 1/24

S8030-0014

Micro Test Tube 0.4 Ml 1/24

S8030-0015

Micro Test Tube 0.5 Ml 1/24

S8030-0013

Rotor Standard 24 At Aerosol-Tight, 24 X 1.5/2 Ml Tubes Incl. Aerosol-Tight Rotor Lid, Microcentrifuge 24

S8030-0010

Rotor Lid Standard 24 At Aerosol-Tight, Aluminum

S8030-0011
