Rite-Hite High Performance Modular Door Fastrax FR

Clean, check all connections with disconnect off

Make sure all wires are free from moving parts

Operate door and make sure all operations are functioning properly

Verify drive tube gear is centered over track groove. Make sure bearing set screws and mounting bolts are tight

Verify Encoder chain and sprocket set screws are tight. Check open and close positions, adjust as required

Verify lintel seal is sealing wall properly

Check junction box and plug connections

With power off, verify chain hoist opens door. Lubricate chain, sprockets and check alignment

Inspect track retention edging, replace if cracked

Lubricate radials and tracks with food grade synthetic grease (Super Lube)

Is it required to remove the existing grease prior to adding new?

Verify proper width and tighten all hardware

Patch immediately to prevent condensation or frost buildup

Check drive spheres, if missing or damaged, replace

Sign off on the curtain maintenance

All devices are operating properly

Curtain Fans are powered and working

Fans are positioned properly and are removing condensation from the curtain

Both photoeyes reverse the curtain

LED’s on receiver should go on/off

Emitter and receiver lens are clean

Air bag is inflated, free of tears and providing an adequate seal against curtain and the wall

Warm air existing exhaust holes

Perform visual inspection for damage

Use air hose to remove dust and debris

Sign off on the door assembly maintenance
