Parker Hannifin Boiler T6800

The system must be thoroughly cleaned before effective control can be maintained.

Once the system is cleaned, a liquid water treatment is recommended to prevent scale, corrosion and foaming.

A liquid treatment should be used to prevent damage to the pump seal.

Parker Boiler Control or equal should be used to properly maintain the system.

Add one quart minimum of Parker Boiler Control for each 50 gallons of water in the system.

This liquid should be poured directly into the expansion tank of the system.

Parker Boiler Control will raise the pH to the safe recommended level of 8.0 to 9.0.

Carefully maintain the system to eliminate the loss of water due to leakage in pipes, valves, fittings, seals and packing glands.

Operating pressure or temperature

AS IS combustion analysis at High fire

AS IS combustion analysis at Low fire

Boiler tubes & heat transfer surfaces check

Warning: This procedure requires trained personnel with PPE!

Select the type of installation

Enter the amount of water in the system (in gallons)

Enter the amount of Parker Clean-1 or Parker Solve-1 used (in pounds)

Enter the temperature of the cleaning solution

Was the system circulated with the cleaning solution for 2 to 4 hours?

Was the cleaning solution completely drained from the boiler and system?

Was the system flushed with clean water to completely remove all cleaning solutions?

Enter the temperature of the boiler after refilling and venting the system
