Mitsubishi Split-Type Air Conditioner PLA-A18BA4
Create an account to install this asset package.
Maintenance Plans for Mitsubishi Split-Type Air Conditioner Model PLA-A18BA4
Integrate maintenance plans directly into your work orders in MaintainX.
Fan And Fan Motor Replacement
Remove the electrical box
Upload a photo of the removed electrical box
Remove the bell mouth (3 screws)
Upload a photo of the removed bell mouth
Remove the turbo fan nut
Pull out the turbo fan
Remove the wire cover (3 screws)
Remove 2 wiring clamps
Disconnect the connector of the fan motor (CNMF)
Air Intake Grille Replacement
Slide the knob of air intake grille toward the arrow 1 to open the air intake grille
Remove drop prevention hook from the panel
Slide the shaft in the hinge to the direction of the arrow 2 and remove the air intake grille
Sign off on the air intake grille replacement
TH2 And TH5 Thermistors Replacement
Drain pan removed
Upload a photo of the removed drain pan
Turbo fan removed
Upload a photo of the removed turbo fan
2 wiring clamps removed
Upload a photo of the removed wiring clamps
Coil plate removed
Upload a photo of the removed coil plate
Thermistors removed from the holders
Drain Pump And Float Switch Replacement
Warning: Ensure the power is off before starting the procedure
Upload a photo of the drain pan before removal
Drain pan removed successfully
Upload a photo of the hose before removal
Hose removed successfully
Upload a photo of the drain pump assembly before removal
Drain pump assembly removed successfully
Upload a photo of the drain pump before removal
Drain pump removed successfully
Drain Pan Replacement
Remove the air intake grille and the filter
Remove the 2 screws from the electrical box cover
Disconnect the connectors
Remove the panel
Remove the electrical wiring service panel (3 screws)
Remove the drain pump wire cover (1 screw)
Remove the electrical box
Remove the bell mouth
Remove the 4 screws and pull out the drain pan
