Midmark Barrier-Free Exam Chair 224-003

Warning: This maintenance check requires trained personnel with PPE!

Power cord(s) free of cuts or other visible damage

All fasteners in place and tightened securely

All mechanical functions operating properly

Amount of light machine oil used for lubrication

Have a qualified service technician inspect your equipment every twelve months

Any damage or loose parts identified?

If damage or loose parts are identified, the examination chair should be removed from use and serviced. Failure to do so may result in injury

Sign off on the exam chair maintenance

Control levers located under the back section on each side, activate and deactivate the Clean Assist™ Roller System. The rollers are located on each corner of the chair to allow positioning of chair.

Caution: To prevent injury, never activate / deactivate Clean Assist™ Roller System or move chair with patient aboard. Use caution when moving chair.

Equipment Alert: Be sure to activate both control levers.

Equipment Alert: The intended use of the Clean Assist™ Roller System is for chair positioning within the exam room only.

WARNING: To avoid risk of fall, the Clean Assist™ Roller System must be disengaged while a patient ingresses or egresses the chair.

To activate Clean Assist™ Roller System:

A) Raise back section 30 to 45 degrees.

B) Ensure chair is at least two inches higher than its lowest position.

C) Move control levers on each side of chair to the Clean Assist™ Roller System engagement position.

WARNING: The upholstery should be inspected before each use and replaced if punctured or otherwise damaged.

Equipment Alert: The upholstery is resistant to most medicinal-type stains, but may be damaged by solvents and dyes. Immediately remove any fluids spilled on the upholstery.

Wash your upholstery weekly with a mild liquid soap and water mixture, rinse with clear water and dry completely to remove disinfection cleaner build-up.

Disinfect your upholstery with a solution of standard bleach and water mixed 1 in 10 (10%) or chlorine based cleaners. Follow this with a clear water rinse and thorough drying of material. See current CDC Guideline for Disinfection & Sterilization in Healthcare Facilities.

To minimize damage caused by disinfectant cleaner residue build-up, do not allow disinfectants to pool on the upholstery surface. Once the approved contact time has been obtained, remove and dry excess liquid remaining on the surface.

Detailed care and maintenance instructions are included with your product. This information is also available on midmark.com in the Technical library under the User Information tab for your product.

Painted Metal / Plastic Surfaces

Clean the painted metal and plastic surfaces weekly using a clean soft cloth, and mild cleaner.;
