Lincoln Electric Welder RED-D-ARC ZR-10

Create an account to install this asset package.

Maintenance Plans for Lincoln Electric Welder Model RED-D-ARC ZR-10

Integrate maintenance plans directly into your work orders in MaintainX.

Routine Maintenance

- At the end of each day’s use, refill the fuel tank to minimize moisture condensation in the tank. Running out of fuel tends to draw dirt into the fuel system. Also, check the crankcase oil level and add oil if indicated;

Run this procedure

Air Cleaner Cleaning

- Clean the air cleaner;

Run this procedure

6 Monthly Maintenance

- Change Engine oil

- Clean spark plug

- Clean spark arrestor

- Check fuel filter;

Run this procedure

Annual Maintenance

- Replace Engine Oil Filter

- Replace Air Cleaner

- Replace Spark Plug

- Check-Adjust engine speed

- Check-Readjust valve clearance

- Replace fuel filter;

Run this procedure

Battery Maintenance

- When replacing, jumping, or otherwise connecting the battery to the battery cables, the proper polarity must be observed. Failure to observe the proper polarity could result in damage to the charging circuit. The positive (+) battery cable has a red terminal cover

- If the battery requires charging from an external charger, disconnect the negative battery cable first and then the positive battery cable before attaching the charger leads. Failure to do so can result in damage to the internal charger components. When reconnecting the cables, connect the positive cable first and the negative cable last;

Run this procedure
