JCB Backhoe Loader 4CX-4WS PC
Create an account to install this asset package.
Maintenance Plans for JCB Backhoe Loader Model 4CX-4WS PC
Integrate maintenance plans directly into your work orders in MaintainX.
2000 Hours / 2 Yeary Loader Engine Maintenance
- Change Engine Oil and Filter (AK and AR Build)
- Change Engine Oil and Filter (RE and RG Build)
- Change Engine Air Cleaner Outer Element
- Change Air Cleaner Inner Element
- Change Engine Fuel Filter (AK and AR Build)
- Change Engine Fuel Filter (RE and RG Build)
- Clean Lift Pump Strainer (AK and AR Build Only)
- Check Coolant Quality/Level
- Drain and Clean Engine Fuel Sedimenter
Loader Check
Inspect steelwork for damage
Note damaged paintwork for future repair
All pivot pins are correctly in place and secured by their locking devices
Steps and handrails are undamaged and secure
No broken or cracked window glass
Replace damaged items
All bucket teeth are undamaged and secure
All lamp lenses are undamaged
Tyres are undamaged and free from penetration by sharp objects
1000 Hours / 1 Yeary Loader Engine Maintenance
- Change Engine Oil and Filter (AK and AR Build)
- Change Engine Oil and Filter (RE and RG Build)
- Change Engine Air Cleaner Outer Element
- Change Engine Fuel Filter (AK and AR Build)
- Change Engine Fuel Filter (RE and RG Build)
- Clean Lift Pump Strainer (AK and AR Build Only)
- Check Coolant Quality/Level
- Drain and Clean Engine Fuel Sedimenter
- Check Fan Belt Tension/Condition
10 Hours / 1 Daily Loader Maintenance
Check Engine Oil Level
Check Coolant Quality/Level
Check Transmission Oil Level
Check Tyre Pressures
Check Tyre Condition
Grease Front Axle Main Pivot
Check Hydraulic Oil Level
Sign off on the daily loader maintenance
500 Hours / 6 Monthy Loader Transmission Maintenance
Check Transmission Oil Level
Change Transmission Filter
Check Axle Oil Level (incl. Hubs when applicable)
Change Axle Oil - Limited Slip Differential
Check Tyre Pressures/Condition
Check Front Hub Bearings
Security/Grease Drive Shafts
Check Steer Axle Movement/Shimming
Grease Steer Axle Pivots and Linkages
Parts for JCB Backhoe Loader 4CX-4WS PC
Access the parts list for your equipment in MaintainX.
Flow Test Adapter
460/15708
Banjo Bolt
460/15707
Bonded Washer, 1/4 in. BSP
1406/0011
Bonded Washer, 5/8 in. BSP
1406/0014
Bonded Washer, 1/2 in. BSP
1406/0018
Flow Test Adapter
460/15708
Banjo Bolt
460/15707
Bonded Washer, 1/4 in. BSP
1406/0011
Bonded Washer, 5/8 in. BSP
1406/0014
Bonded Washer, 1/2 in. BSP
1406/0018
Flow Test Adapter
460/15708
Banjo Bolt
460/15707
Bonded Washer, 1/4 in. BSP
1406/0011
Bonded Washer, 5/8 in. BSP
1406/0014
Bonded Washer, 1/2 in. BSP
1406/0018
Unlock efficiency
with MaintainX CoPilot
MaintainX CoPilot is your expert colleague, on call 24/7, helping your team find the answers they need to keep equipment running.
