Ingersoll Rand Mobile Compressor 9/230HA

Remove Y–strainer screens at the bottom of the moisture separator and both filters and clean out any residue.

Verify that the orifices below the Y–strainers are not clogged.

Verify that the piping from the orifice purge points to the exhaust system is not clogged.

Sign off on the system maintenance

WARNING: Do not remove the filter(s) without first making sure that the machine is stopped and the system has been completely relieved of all air pressure.

• Disconnect all hoses and tubes from the separator tank cover plate.

• Remove the drop–tube from the separator tank cover plate and then remove the cover plate. Remove the separator element.

• Examine the filter element. Examine all hoses and tubes, and replace if necessary.

• Thoroughly clean the orifice/drop tube and filter gasket contact area before reassembly. Install the new element.

WARNING! Do not remove the staple from the anti–static gasket on the separator element since it serves to ground any possible static build–up.Do not use gasket sealant since this will affect electrical conductance.

* Every 1500 Hours Injection Nozzle Check

• Check Wheels (Bearings, Seals, etc.)

• Test Shutdown Switch Settings

• Check Scavenger Orifice & Related Parts

• Replace Oil Separator Element

All tasks completed successfully?

Sign off on the maintenance tasks

Warning: Never remove and replace element(s) when the machine is running.

Cleaned the exterior of the filter housing?

Removed the filter element by releasing the nut?

Is the safety element to be renewed?

Cleaned the interior of the filter housing prior to removing the safety element?

Checked for cracks, holes or any other damage to the element?

Checked the seal at the end of the element and replaced if any sign of damage is evident?

Assembled the new element into the filter housing ensuring that the seal seats properly?

Secured the element in the housing by hand tightening the nut?
