Ingersoll Rand Mobile Compressor 17/235HA

• Check Engine Oil Level • Check Radiator Coolant Level • Check Gauges/Lamps • Check Air Cleaner Service Indicators • Check Fuel Tank (Fill at end of day) • Check Fuel/Water Separator Drain • Check Oil Leaks • Check Fuel Leaks • Check Drain Water From Fuel Filters • Check Coolant Leaks • Check Radiator Filler Cap

• Check Lights (running, brake, & turn)

Warning: This procedure requires trained personnel with PPE!

Warning: Hot engine coolant and steam can cause injury. Follow the instructions provided by the antifreeze supplier when adding or draining the antifreeze solution.

Oil, grease and dirt accumulation on the exterior surfaces of the oil cooler and radiator?

Oil, grease and dirt removed from the exterior core of the cooler?

Engine cooling system fully depressurised?

Sign off on the compressor oil cooler and engine radiator air charge cooler maintenance

Warning: This inspection requires trained personnel with PPE!

Scavenge line runs from the combined orifice/drop tube in the separator tank to the orifice fitting located in the airend

Orifice, check valve and hoses examined

Scavenge line and tube clear of any obstruction

Enter the compressor's hour meter reading

Sign off on the scavenge line inspection

Check Hoses (Oil, Air, Intake, etc.)

Check Automatic Shutdown System

Check Compressor heat exchanger exterior

Check Engine heat exchanger exterior

Sign off on the monthly mobile compressor maintenance

* Every 1500 Hours Injection Nozzle Check

• Check Wheels (Bearings, Seals, etc.)

• Test Shutdown Switch Settings

• Check Scavenger Orifice & Related Parts

• Replace Oil Separator Element
