Immergas Boiler VICTRIX PRO V2 150 G20

Unscrew the fixing screws of the ignition and detection electrodes and remove them.

Remove the insulating panel by actuating a blade under its surface.

Remove the residue of the fixing adhesive from the surface of the manifold.

Replace the insulating panel using suitable sealant.

Refit the ignition and detection electrodes using the previously removed screws and replace the relative gaskets.

Use damp cloths and neutral detergent to clean the appliance casing

Ensure no abrasive or powder detergents are used

Verify compliance with standards

Is the appliance's integrity preserved?

Are the safety features intact?

Clean the flue side of the heat exchanger.

Check the correct positioning, integrity and cleanliness of the detection and ignition electrode; remove any oxide present.

Remove deposits from the combustion chamber and clean the heat exchanger coils using nylon or broomcorn brushes.

Check the integrity of the insulating panels inside the combustion chamber and replace if damaged.

Visually check for water leaks or oxidation from/on connections and traces of condensate residues inside the sealed chamber.

Check the contents of the condensate drain trap.
