The Hyster-Yale Forklift H100XL is a robust industrial forklift designed for heavy-duty applications. Known for its reliability and efficiency, this model excels in material handling tasks, making it an ideal choice for warehouses and manufacturing facilities. Optimize your operations with the H100XL's advanced features and durable construction.
Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant
Complete asset maintenance, one click away
Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.
Documents & Manuals
Find all the essential guides in one place.
Tensioning Guide- Belt-diagram
- C-120 pulleys
+ 13 more
Work Order Templates
Pre-built workflows to keep your asset running smoothly.
- Daily Electrical System Inspection
- Replace Roller and Pulley
- Install Engine B-120
+ 29 more
Procedures
Integrate maintenance plans directly into your work orders.
- Motion Industries
- Applied Industrial Technologies
- Electrical Brothers
+ 5 more
Parts
Access the parts list for your equipment in MaintainX.
- Drive Motor
- B2 Rollers
- Tensioning System
+ 40 more
Hyster-Yale Forklift H100XL
Create an account to install this asset package.
Maintenance Plans for Hyster-Yale Forklift Model H100XL
Integrate maintenance plans directly into your work orders in MaintainX.
2000 Hourly / 1 Yearly Filter Replacement
Air filter element replaced
Gasoline fuel filter replaced
LPG fuel filter replaced
Hydraulic system oil filter replaced
Oil clutch system oil filter replaced
Sign off on the filter replacement
1000 Hourly / 6 Monthly Forklift Lubrication
Lubricate parking brakes
Lubricate clutch, brake and inching/brake pedals
Lubricate pedals, levers, linkages, cables, hinges, seat rails
Sign off on the forklift lubrication
2000 Hourly / 1 Yearly Forklift Maintenance
Clean and inspect service brakes
Inspect engine vacuum, fuel lines and fittings
Inspect lock off for leaks and ensure lock off closing
Test LPG/gas regulator pressure
Check indicator light of oxygen sensor
Inspect low pressure regulator for oil buildup and leaks
Check air induction system for leaks
Check manifold for vacuum leaks
Check throttle shaft for sticking
8 Hourly / 1 Daily Forklift Check
Check Hydraulic Oil Level
Check engine oil level
Check diesel engine oil PERKINS 4.2482 level
Check diesel engine oil PERKINS 1004-42 level
Check diesel engine oil PERKINS 1104C-44 level
Check powershift transmission oil level
Check oil clutch system oil level
Check fuel tank level
Check the cooling system
1000 Hourly / 6 Monthly Forklift Maintenance
Replace final diesel fuel filter
Replace spark plugs
Check PCV Valve
Check timing of the engines
Check engine valve adjustments
Check manual transmission, speed reducer and differential oil
Check single speed powershift transmission
Replace Fuel filter
Replace primary diesel fuel filter
Parts for Hyster-Yale Forklift H100XL
Access the parts list for your equipment in MaintainX.
Universal Premium Hydraulic Oil
336831
Silicon Spray
328388
Universal Premium Hydraulic Oil
336831
Silicon Spray
328388
Universal Premium Hydraulic Oil
336831
Silicon Spray
328388
