Honeywell Fire Alarm Control Panel MS-4

1. Mark and predrill holes for the top two keyhole mounting bolts

2. Install two upper fasteners in the wall with the screw heads protruding approximately 1⁄4”

3. Using the upper keyholes, mount the backbox over the two screws

4. Mark the lower two holes, remove the backbox from the wall and drill the mounting holes

5. Mount the backbox, install the remaining fasteners and tighten all screws

When batteries larger than 7 Amp Hour, up to 18 Amp Hour, are being used, the BB-17F battery box (or UL listed equivalent) must be installed. To install the BB-17F:

1. Mount the FACP cabinet to the wall

2. Remove knockouts on the bottom of the FACP cabinet and top of the BB-17F

3. Using conduit, hang the BB-17F from the FACP cabinet making sure there is at least 1⁄2” of clearance between the two cabinets

Warning: The control panel is in an off-normal condition and does not provide fire protection during Walktest mode.

No active alarms on the system?

Upon entering Walktest mode, the following conditions should occur:

Supervision relay disabled (MS-4 only)

I3 smoke detectors entered their own test mode causing their LEDs to flash twice every five seconds
