Hobart Dishwasher CL44EN

- Clean the machine thoroughly at the end of each working shift, at least twice a day. Use only products formulated to be safe on stainless steel. Use a damp cloth and mild soapy water

1. Press the POWER key on the keypad to turn the machine Off

WARNING! Disconnect the electrical power to the machine and follow lockout/ tagout procedures before you begin cleaning. There may be multiple circuits. Be sure all circuits are disconnected

2. Open the doors. Standard door interlock switches prevent machine operation with inspection doors open

3. Visually inspect the upper and lower final rinse nozzles to make sure they are free of debris

4. Open drain(s) by pulling drain lever(s) up

5. Remove wash arms. Remove wash arm end caps and push any nozzle obstructions into the wash arms

Thoroughly flush the wash arms in a sink. Replace the wash arm end caps

6. Before removing strainer baskets) and pan(s), clean off any debris from machine walls using a hose with spray nozzle

WARNING! Disconnect the electrical power to the machine and follow lockout/tagout procedures. There may be multiple circuits. Be sure all circuits are disconnected.

Vent of the dishwasher checked for obstructions when cool

Contact your local Hobart Service office for any repairs or adjustments needed on this equipment. If a gas orifice fitting is to be replaced, have it serviced by qualified HobartService personnel. Long-term service contracts are available on this and other Hobart products.

Sign off on the vent maintenance
