Graco Pump System 24F092

Create an account to install this asset package.

Maintenance Plans for Graco Pump System Model 24F092

Integrate maintenance plans directly into your work orders in MaintainX.

1 Monthly Air Filter Maintenance

⚠️ Removing a pressurized air filter bowl could cause serious injury. Depressurize air line before servicing.

Pump systems have two air filters: the 5 micron air manifold filter (209) and the 40 micron pump air filter (206). Meter systems have only the 5 micron filter (209). Check filters daily and replace element(s) as needed. Order 15D909 (5 micron) or 15D890 (40 micron).

Close main air shutoff valve on air supply line and on system. Depressurize air line.

Remove the filter cover (A).

Unscrew the filter bowl (B).

Remove and replace element (206a, 209a).

Screw filter bowl (B) on securely. Install cover (A).

Note: Check Fluid Filter Daily.

Sign off on the air filter maintenance

Run this procedure

Advanced Fluid Control Module (AFCM) Replacement

Follow Before Servicing, page 13. Disconnect main power.

Control Box opened

All cables from AFCM (302) removed

Note of cable locations

Ground wire disconnected from ground screw (GS)

Four mounting screws (303) loosened

AFCM slid up and out of keyhole slots

Follow steps in reverse order to install a new AFCM. See electrical schematic for cable connection information.

Upload a photo of the new AFCM installed

Run this procedure

Air Controls Maintenance

Before Servicing

Disconnect pump air lines, main air line, and solenoid air line

Loosen four screws (8) from sides of frame

Slide the assembly up and out to remove

Replace Pressure Gauge(s)

Disconnect air lines to gauges (203)

Remove mounting screws (203a)

Remove fittings (211) and gauges (203)

Replace Air Regulators

Run this procedure

Alarm Replacement

Follow Before Servicing, page 13. Disconnect main power.

Control Box opened

Alarm wires disconnected from alarm (311)

Alarm jam/mounting nut unscrewed and alarm removed

New alarm assembled and alarm wires reconnected

Control Box closed and power restored

Run this procedure

Alternator Regulator Replacement

Follow Before Servicing, page 13. Disconnect main air.

Open Control Box.

Disconnect supply air line from regulator assembly (505).

Loosen air regulator swivel fittings (506) and remove from solenoid module.

Repair or replace alternator regulator parts as necessary. See Alternator Power Assembly, page 46, for repair parts. Replace air regulator swivel fitting (506).

Reconnect air line. Set regulator air pressure to 18 psi (0.12 MPa, 1.2 bar).

NOTICE: To avoid damage to the alternator, do not set the regulator air pressure higher than 18 psi (0.12 MPa, 1.2 bar).

Close Control Box and restore power.

Sign off on the alternator regulator replacement

Run this procedure
