Maintenance Plans for Graco Pump System Model 24F093

Integrate maintenance plans directly into your work orders in MaintainX.

1 Monthly Air Filter Maintenance

⚠️ Removing a pressurized air filter bowl could cause serious injury. Depressurize air line before servicing.

Pump systems have two air filters: the 5 micron air manifold filter (209) and the 40 micron pump air filter (206). Meter systems have only the 5 micron filter (209). Check filters daily and replace element(s) as needed. Order 15D909 (5 micron) or 15D890 (40 micron).

Close main air shutoff valve on air supply line and on system. Depressurize air line.

Remove the filter cover (A).

Unscrew the filter bowl (B).

Remove and replace element (206a, 209a).

Screw filter bowl (B) on securely. Install cover (A).

Note: Check Fluid Filter Daily.

Run this procedure

Advanced Fluid Control Module (AFCM) Replacement

Follow Before Servicing, page 13. Disconnect main power.

Control Box opened

All cables from AFCM (302) removed and cable locations noted

Ground wire disconnected from ground screw (GS)

Four mounting screws (303) loosened

AFCM slid up and out of keyhole slots

Follow steps in reverse order to install a new AFCM. See electrical schematic for cable connection information.

Follow instructions in Manual 3A1244 to update the software on the new AFCM.

Control Box closed and power restored

Run this procedure

Air Controls Maintenance

Remove Air Control Assembly

Followed Before Servicing instructions

Disconnected pump air lines, main air line, and solenoid air line

Loosened four screws from sides of frame

Slid the assembly up and out to remove

Replace Pressure Gauge(s)

Disconnected air lines to gauges

Removed mounting screws

Removed fittings and gauges

Run this procedure

Alarm Replacement

Follow Before Servicing, page 13. Disconnect main power.

Control Box opened

Alarm wires disconnected from alarm (311)

Alarm jam/mounting nut unscrewed and alarm removed

New alarm assembled and alarm wires reconnected

Control Box closed and power restored

Run this procedure

Alternator Regulator Replacement

Follow Before Servicing, page 13. Disconnect main air.

Control Box opened

Supply air line disconnected from regulator assembly (505)

Air regulator swivel fittings (506) loosened and removed from solenoid module

Select the alternator regulator parts repaired or replaced

Set regulator air pressure to 18 psi (0.12 MPa, 1.2 bar)

NOTICE: To avoid damage to the alternator, do not set the regulator air pressure higher than 18 psi (0.12 MPa, 1.2 bar)

Control Box closed and power restored

Sign off on the alternator regulator replacement

Run this procedure
