Gardner Denver Refrigerated Dryer 9VXRD1000
Create an account to install this asset package.
Maintenance Plans for Gardner Denver Refrigerated Dryer Model 9VXRD1000
Integrate maintenance plans directly into your work orders in MaintainX.
1 Yearly Oil Separator/Filter Replacement
A. When to replace the Separator/Filters
Pressure drop across dryer
Pressure drop across dryer is excessive?
Pressure drop across dryer exceeds 10 psi (0.7 bar)?
B. Description of the Separator/Filter Assembly
C. Replacement of the Separator/Filters
CAUTION! Depressurize the unit before servicing. Failure to do this may result in injury.
Unit depressurized?
a. Remove the insulation from the upper shell cap.
1 Monthly Condenser Coil Cleaning
1. Air-cooled - clean off accumulated dust and dirt monthly. - A factory mounted blow gun is provided for this pur- pose.
2. Water-cooled - clean strainer monthly, more often if required.
- Shut off water, remove small plug to relieve pressure, then remove large plug to remove strainer.
- Clean strainer and replace.;
1 Daily Dryer Maintenance
Check separator daily to be sure automatic drain is discharging.
NOTE: Units with two stage filtration have two sets of drains.
Blow down separator weekly by pushing test button on control panel.
Parts for Gardner Denver Refrigerated Dryer 9VXRD1000
Access the parts list for your equipment in MaintainX.
Compressor (208-230/3/60)
G4130-106-80
Fan motor (208-230/3/60)
G6150-238-54
Fan blade (208-230/3/60)
G4140-227-30
Crankcase heater (208-230/3/60)
G5920-330-18
Condenser (air-cooled) (208-230/3/60)
G4130-112-35
Compressor (208-230/3/60)
G4130-106-80
Fan motor (208-230/3/60)
G6150-238-54
Fan blade (208-230/3/60)
G4140-227-30
Crankcase heater (208-230/3/60)
G5920-330-18
Condenser (air-cooled) (208-230/3/60)
G4130-112-35
Compressor (208-230/3/60)
G4130-106-80
Fan motor (208-230/3/60)
G6150-238-54
Fan blade (208-230/3/60)
G4140-227-30
Crankcase heater (208-230/3/60)
G5920-330-18
Condenser (air-cooled) (208-230/3/60)
G4130-112-35
