Maintenance Plans for Daikin Outdoor Unit For Reverse Cycle System Model RY100LUY1

Integrate maintenance plans directly into your work orders in MaintainX.

Fan Motor Pulse Check

Check mark

(1) Set operation OFF and power OFF. Disconnect the connector.

Check mark

(2) Check that the voltage between the pins 3 - 4 is about 15 VDC.

Check mark

(3) Check that the voltage between the pins 1 - 4 is about 5 VDC.

Check mark

(4) Keep operation OFF and power OFF. Connect the connector.

Check mark

(5) Check whether 2 pulses (0 and 5 VDC) are output 4 times at the pins 1 - 4 when the fan motor is rotated 1 turn by hand.

Check mark

If NG in steps 2 and 3 Defective PCB

Check mark

Replace the outdoor unit PCB.

Check mark

If NG in step 5

Check mark

Defective Hall IC

Run this procedureArrow right

Power Transistor Check

Check mark

Warning: Do not touch the energized part (high voltage part) for at least 10 minutes after the power is turned OFF.

Check mark

Be sure to touch the earth terminal with a hand to release static electricity from the body (to prevent PCB from being damaged).

Check mark

Residual electric charge of the power transistor (should be DC 50V or less)

Check mark

Outdoor unit fan has stopped

Check mark

Remove the wire connecting the power transistor and the compressor. Remove it from the compressor terminal side. During this work, be careful not to deform. Faston terminal at the end of the relay wire.

Check mark

Resistance measurement for phase 1

Check mark

Resistance measurement for phase 2

Check mark

Resistance measurement for phase 3

Check mark

Is the resistance value equal to 5 times or more than the other resistance values?

Run this procedureArrow right

Fan Motor Connector Check

Check mark

Check for Fan Motor Connector (Signal Line)

Check mark

(1) Turn the power supply OFF.

Check mark

For except FBQ

Check mark

(2) With the fan motor connector disconnected, measure the resistance between each pin, then make sure that the resistance is more than the value mentioned in the following table.

Check mark

For FBQ

Check mark

(2) With the fan motor connector disconnected, measure the resistance between each pin, then make sure that the resistance is balanced in ±30%.

Check mark

Check for Fan Motor Connector (Power Supply Line)

Check mark

(1) Turn the power supply OFF.

Check mark

With the relay connector disconnected, measure the resistance between UVW phases of the connector (3 cores) at the motor side, then make sure that the resistance between each phase is balanced and not short-circuited.;

Run this procedureArrow right

Abnormal High Pressure Check

Check mark

Warning: High pressure checks should be performed by trained personnel only

Check mark

Enter the current pressure level

Check mark

Is the pressure level above the normal range?

Check mark

If pressure is above normal, proceed with the following checks

Check mark

Check if the condenser side is causing the high pressure

Check mark

List the possible causes of high pressure

Check mark

Sign off on the high pressure check

Run this procedureArrow right

Thermistor Check

Check mark

Warning: Disconnect the thermistor from the PCB before proceeding

Check mark

Thermistor disconnected from the PCB

Check mark

Enter the temperature reading

Check mark

Enter the resistor value

Check mark

Check if the measured values correspond with the values in the table

Check mark

Sign off on the thermistor check
