Daikin Indoor Unit Multi-Split Type Air Conditioner CTXG18QVJUW

Warning: This procedure requires trained personnel with PPE!

EV connector correctly inserted in the PCB

All EVs generate a latching sound after power cycle

If any EV does not generate a latching sound, proceed to next step

If there is no continuity between the pins, the EV coil is faulty

Warning: Disconnect the connectors of the thermistors from the PCB before proceeding

Thermistors disconnected from the PCB

Measure the resistance of each thermistor using a multimeter

When the room temperature thermistor is soldered on a PCB, remove the PCB from the control PCB to measure the resistance

Room temperature thermistor removed from the PCB

Measure the resistance of the room temperature thermistor

When the connector of indoor heat exchanger thermistor is soldered on a PCB, remove the thermistor and measure the resistance

Indoor heat exchanger thermistor removed from the PCB

Measure the resistance of the indoor heat exchanger thermistor

Warning: Ensure the voltage between (+) and (-) of the power module is about 0 V before proceeding

Disconnect the compressor harness connector from the outdoor unit PCB. To disengage the connector, press the protrusion on the connector.

Connector disengaged successfully?

Measure resistance between the (+) or (-) terminal of the power module and the U, V, or W terminal of the compressor with a multimeter.

Enter the resistance measurement

Evaluate the measurement results

Sign off on the power module check

Warning: Ensure the voltage between (+) and (–) of the diode bridge (DB1) is about 0 V before proceeding

Enter the voltage between (+) and (–) of the diode bridge (DB1)

Measure the resistance between the pins of the DB1 referring to the table below.

Enter the resistance between the pins of the DB1

Is the resistance ∞ or less than 1 kΩ?

If the resistance is ∞ or less than 1 kΩ, short circuit occurs on the main circuit.

Sign off on the main circuit short check

Warning: This procedure requires trained personnel with PPE!

Control voltage between the pins 4 - 3

Rotation command voltage between the pins 4 - 2

Pulses at the pins 4 - 1 when the outdoor fan motor is rotated 1 turn by hand
