Clark Forklift C35L

Warning: This maintenance check requires trained personnel with PPE!

Uprights raised to maximum height?

Hoist function fully operational?

Only trained personnel may repair and maintain LPG units. Contact your CLARK dealer when maintenance or repairs need to be carried out.

LPG system checked for operational safety?

Describe any issues found during the check

Sign off on the weekly forklift maintenance

Warning: This inspection requires trained personnel with knowledge of LPG systems!

LPG system in operationally safe state?

Change the engine oil / Replace engine oil filter

Grease the sealing ring on the new filter cartridge and screw in the cartridge until it is hand tight

Remove the oil pan drain plug to drain old oil after the truck has been in operation and the engine (oil) is at operating temperature

Check for leaks after changing oil and installing new filter

1. Close the shut-off valve of the LPG tank to be changed by turning the valve as far as possible clockwise. Let the engine run until it stops of its own accord. By doing this you will avoid the risk of liquefied gas spraying out from the hose (danger of frostbite) when you loosen the union.

3. Separate the hose from the LPG tank (left hand thread). Close the connection on the LPG-tank with the cap nut.

4. Slacken the strap holding the LPG tank and take away the empty LPG tank.

5. Replace the empty LPG tank with a full one. Check that the unions at the end of the hose and on the LPG tank are of the same type. Take care that you place the LPG tank in the correct position. The union for the hose must face downwards.

6. Secure the LPG tank strap and connect the hose.

7. Open the shut-off valve of the LPG tank slowly by turning it anticlockwise as far as it will go. Check the LPG system for tightness.

Extraordinary inspection of the LPG system

Check the tightening torque of critical fastening elements

Grease steering tie rods and steering knuckle

Cleaning, checking and lubricating the upright inside rails, rollers and side loader

Check the air intake system for leaks

Clean or replace engine air filter (GAS/LPG)

Replace transmission oil C15-35

Check / lubricate steer axle wheel bearings

Replace hydraulic sump oil and hydraulic oil filter

Check injection nozzles and injection timing (diesel engine)

Sign off on the forklift maintenance
