Caterpillar Compact Wheel Loader 906M

- Change Transfer Drive Oil.1.3 L (0.34 gal). Changed every 1,000 hours after the initial 500 hour change (i.e., 1,500 hours, 2,500 hours, etc.)

- Change Front Differential and Final Drive Oil. Diff = 8 L (2.11 gal), Hub = 0.8 L (0.21 gal) each. Changed every 1,000 hours after the initial 500 hour change (i.e., 1,500 hours, 2,500 hours, etc.)

- Change Rear Differential and Final Drive Oil. Diff = 8 L (2.11 gal), Hub = 0.8 L (0.21 gal) each. Changed every 1,000 hours after the initial 500 hour change (i.e., 1,500 hours, 2,500 hours, etc.);

Sign off on the 3000 Hours Loader Maintenance

- Change Transfer Drive Oil. Sampling Only

- Change Front Differential and Final Drive Oil. Sampling Only

- Change Rear Differential and Final Drive Oil. Sampling Only

- Change Engine Oil / Filter Element. 11.2 L (2.96 gal)

- Lubricate Machine with Prime Application Grease

- Change Hydraulic Filter Element;

- Check DEF Injector every 5000 hours

- Add Engine Coolant Extender 0.34 L (0.09 gal) (depending on S•O•SSM Coolant Sampling Results) every 6000 hours

- Check DEF Manifold Filter Element every 10000 Hours

- Change Engine Collant 17 L (4.49 gal) every 12000 Hours;

Warning: This maintenance check requires trained personnel with PPE!

Brake Fluid changed (if equipped)?

Sign off on the loader maintenance
