Atlas Copco Stationary Air Compressor ZT18FF

WARNING! Never run the compressor without safety valves. No adjustments are allowed

Safety valves present and functional

Enter the pressure at which the valve opens

If a valve does not open at the pressure specified in section 7.2, consult Atlas Copco

Sign off on the safety valve testing

Condensate discharged during loading?

Before starting, the level should be in the middle of the sight-glass

Sign off on the daily stationary air compressor check

Coolers checked and cleaned if necessary?

Stop the compressor and switch off the voltage

Drain the compressor sump by opening drain valve (Dmo)

Clean the filter seat, oil the gasket of the new filter and screw it into place until the gasket contacts the seat

Fill the compressor sump to the middle of the oil level sight-glass (SG) with oil

Warning: Always check the display and remedy the trouble if alarm LED is alight or blinks

Is the main screen indicating the compressor outlet pressure?

Is the status of the compressor displayed?

Are the functions of the keys below the display working?

Is there a service message displayed?

Describe the service message if any

Did you carry out the service actions of the indicated plans or replace the component and reset the relevant timer?

Did you consult your Atlas Copco Customer Centre if needed?

Did you check the actual compressor status by pressing the ↓ key from the main screen?
