Atlas Copco Refrigerant Compressed Air Dryer FX50
Create an account to install this asset package.
Maintenance Plans for Atlas Copco Refrigerant Compressed Air Dryer Model FX50
Integrate maintenance plans directly into your work orders in MaintainX.
Automatic Condensate Drain Filter Cleaning
Cock closed
Pressure in the dryer released by pressing the condensate drain “TEST” pushbutton locate on the steam trap
Machine switched off by pressing the STOP button
Supply automatic differential switch turned on
HOT PARTS INSIDE
Panels removed
Stopper removed
Filter removed
Filter cleaned with a jet of air, working from inside to outside
1 Weekly Condenser Cleaning
Switch off the machine by pressing the STOP button
Turn on the supply automatic differential switch
Remove the panels
Clean the condenser fins
DO NOT USE WATER OR SOLVENTS
Close the panels
Brush/blow off the finned surface of the condenser every 1 Week
Replace the filter of automatic condensate drain every 2000 Hours / 1 Year
Replace drain kit every 4000 Hours / 2 Year
Parts for Atlas Copco Refrigerant Compressed Air Dryer FX50
Access the parts list for your equipment in MaintainX.
Spare Plate
1079 9903 48
Condensate Drain
2902016102
Drain Kit
2200902017
Spare Plate
1079 9903 48
Condensate Drain
2902016102
Drain Kit
2200902017
Spare Plate
1079 9903 48
Condensate Drain
2902016102
Drain Kit
2200902017
