Air System Products Oil/Water Separator AS30

Check the oil level in the translucent Oil Container

Is the oil level at or above 3/4 capacity?

Empty the Oil Container if the oil level is at or above 3/4 capacity

Is the bright red Flow Indicator retracted inside the Access Lid?

Refer to Troubleshooting Section if the Flow Indicator is not retracted

Shut off condensate flow to Inlet Diffuser Assembly

Diffuser and Sediment Chamber Removal

Unscrew the four Socket Head Cap Screws that hold the Diffuser to the Vessel

Lift up the Diffuser and move it out of the way

Remove the Sediment Chamber by grasping its edges and lifting slowly

Sediment Chamber Cleaning and Filter Replacement

Tip the Sediment Chamber to pour contents through the Separation Filter back into the vessel

Remove and discard the Separation Filter from the Sediment Chamber

Remove Media Bed(s) and Pre-Absorber from plastic bags

Hose down the Pre-Absorber & Media Bed(s) until water runs clear

Shut off condensate flow to the Inlet Diffuser Assembly

Use polypropylene pad to remove oil from surface water in Media Chamber(s)

Sample Collection and Comparison

Collect a sample from the Sample Valve using the empty Sample Jar.

Hold both the Sample Jar and the Reference Jar to a light for a visual turbidity comparison.

Ensure a spare Pre-Absorber and Media Bed(s) are in stock.

Media Bed and Pre-Absorber Maintenance

Does the Condensate Sample appear cloudy?

Change the Pre-Absorber and Media Bed(s) if the sample is cloudy.
