Air System Products Oil/Water Separator AS180

Remove Media Bed(s) and Pre-Absorber from plastic bags

Hose down the Pre-Absorber & Media Bed(s) until water runs clear

Shut off condensate flow to the Inlet Diffuser Assembly

Use polypropylene pad to remove oil from surface water in Media Chamber(s)

Shut off condensate flow to Inlet Diffuser Assembly

Diffuser and Sediment Chamber Removal

Unscrew the four Socket Head Cap Screws that hold the Diffuser to the Vessel

Lift up the Diffuser and move it out of the way

Remove the Sediment Chamber by grasping its edges and lifting slowly

Sediment Chamber Cleaning and Filter Replacement

Tip the Sediment Chamber to pour contents through the Separation Filter back into the vessel

Remove and discard the Separation Filter from the Sediment Chamber

Collect a sample from the Sample Valve above the Oil Container using the empty Sample Jar

Compare the turbidity of the Sample Jar and the Reference Jar by holding them to a light

Ensure spare Pre-Absorber and Media Bed(s) are in stock

Change the Pre-Absorber and Media Bed(s) if the Condensate Sample appears cloudy

Pour the Condensate Sample back into the Pre-Absorber Chamber

Wash and dry the Sample Jar before returning it to the Placement Well

The Sample Valve extracts the condensate sample 2/3rds of the way through the Media Bed, providing time and security for replacing the Media Bed(s) before PPM violations occur.

Check the oil level in the translucent Oil Container

Is the oil level at or above 3/4 of capacity?

Empty the oil container if the oil level is at or above 3/4 of capacity

Is the bright red Flow Indicator retracted inside the Access Lid?

Refer to Troubleshooting Section if the Flow Indicator is not retracted
