Toyota Forklift 60 - 6FD30

Inspect fork and stopper pin for abnormality

Inspect for misalignment between left and right fork fingers

Inspect each welded parts for deformation, damage, and cracks

Inspect mast and lift bracket for looseness

Inspect wear, damage, and rotating condition of rollers

Inspect mast trip for wear and damage

Inspect tension, deformation, and damage of chain

Inspect abnormality of chain anchor bolt

Inspect for play and looseness in the steering wheel

Inspect the function of the steering wheel

Retighten looseness of mounting of the gear box

Inspect rod, links and arm for looseness and damage

Inspect for oil leaks in the power steering

Inspect power steering for looseness in mounting and linkage

Inspect knuckle for king pin looseness

Sign off on the steering system maintenance

Measure battery fluid specific gravity

Inspect open-circuit in open plug

Inspect open-circuit in intake heater

Sign off on the electric system maintenance

Inspect function, wear, damage, leak and mounting looseness in Master cylinder and wheel cylinder

Inspect Wear of shoe sliding portion and lining

Inspect Shoe operating condition

Inspect Automatic adjuster function

Inspect Backing plate for deformation, cracks and damage

Retighten Backing plate loose mounting

Measure tire inflation pressure of the wheels

Inspect for tire cuts, damage, and uneven wearing

Tighten for loose rim and hub nuts

Inspect for metal chips, pebbles, or foreign matter trapped in tire grooves

Inspect rim, side bearing, and disc wheel for damage

Inspect for abnormal sound and looseness in the front wheel bearing

Inspect for abnormal sound and looseness in the rear wheel bearing
