Toyota Forklift 60 - 5FD23

Measure injection timing in fuel system

Inspect draining of sedimenter in fuel system

Inspect oil clutch mechanism function and leak

Measure stall and hydraulic pressure in torque converter and transmission

Clean hydraulic oil tank and oil strainer

Sign off on the 1000 Hour / 6 Month Maintenance

Inspect fork and stopper pin for abnormality

Inspect for misalignment between left and right fork fingers

Inspect each part for deformation, damage, and cracks at welded parts

Inspect mast and lift bracket for looseness

Inspect wear, damage, and rotating condition of rollers

Inspect mast trip for wear and damage

Inspect tension, deformation, and damage of chain

Inspect for abnormality in chain anchor bolt

- Replace Torque converter oil filter

- Replace Cyclone air cleaner element

- Replace Brake vaIve rubber parts

- Replace Cups and seals for brake master and wheel cylinders;

Measure play and reserve in the brake pedal

Inspect the braking effect of the brake pedal

Inspect the operating force of the parking brake

Inspect the braking effect of the parking brake

Inspect for looseness or damage in the parking brake rod and cable

Inspect for leaks, damage, and mounting condition of the brake pipe

Inspect for leaks and fluid level in the reservoir tank

Measure clearance between drum and lining

Sign off on the braking system maintenance

Inspect clutch for abnormal sound and functioning

Inspect clutch booster function and leak

Inspect transmission fluid level

Inspect transmission gear function and abnormal noise

Inspect for leaks in the differential
