Toyota Forklift 52-6FGU20
Need answers fast?
Explore the manual using AI.
Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant
Manual for Toyota Forklift 52-6FGU20
Complete asset maintenance, one click away
Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.
Documents & Manuals
Find all the essential guides in one place.
Tensioning Guide- Belt-diagram
- C-120 pulleys
+ 13 more
Work Order Templates
Pre-built workflows to keep your asset running smoothly.
- Daily Electrical System Inspection
- Replace Roller and Pulley
- Install Engine B-120
+ 29 more
Procedures
Integrate maintenance plans directly into your work orders.
- Motion Industries
- Applied Industrial Technologies
- Electrical Brothers
+ 5 more
Parts
Access the parts list for your equipment in MaintainX.
- Drive Motor
- B2 Rollers
- Tensioning System
+ 40 more
Toyota Forklift 52-6FGU20
Create an account to install this asset package.
Maintenance Plans for Toyota Forklift Model 52-6FGU20
Integrate maintenance plans directly into your work orders in MaintainX.
500 Hours / 3 Months Maintenance
Tighten loose joint in propeller shaft
Tighten loose joint in axle shaft
Replace engine oil filter
Replace engine coolant
Sign off on the maintenance
170 Hours / 1 Months Material Handling System Maintenance
2000 Hours / 12 Months Material Handling System Inspection
Inspect cracks at fork root and welded part while forklift is new
Inspect wear and damage of mast support bushing
Inspect wear and damage of roller pins
Sign off on the inspection
170 Hours / 1 Months Hydraulic System Maintenance
Inspect loosening and damage of cylinder mounting
Inspect deformation and damage of rod, rod screw and rod end
Inspect cylinder operation
Measure natural drop and natural forward tilt
Inspect for oil leaks and damage in the cylinder
Inspect for wear and damage of the pin and cylinder bearing
Measure lifting speed
Inspect for uneven movement
Inspect for oil leaks and abnormal sound from the oil pump
170 Hours / 1 Months Steering System Maintenance
Inspect for play and looseness in the steering wheel
Inspect the function of the steering wheel
Inspect for oil leaks in the steering valve
Tighten for looseness in mounting of the steering valve
Inspect for oil leaks in the power steering
Inspect for looseness in mounting and linkage of power steering
Inspect for king pin looseness in the knuckle
Sign off on the steering system maintenance
