Thermo Fisher Circulating Water Bath 2865
Create an account to install this asset package.
Maintenance Plans for Thermo Fisher Circulating Water Bath Model 2865
Integrate maintenance plans directly into your work orders in MaintainX.
Temperature Calibration
Preparation
Connect the temperature probe connector to J302 on CPU board
Turn Power switch to the OFF position
Entering Calibration Mode
Press and hold the SETPOINT key while turning Power ON
Press SETPOINT to end LED display test
Press UP until display reads 0012, then press SETPOINT
Calibration Mode
Ensure the unit is in Calibration mode and raw count value appears
Circulating Water Bath Cleaning
General Cleaning
Clean the bath with mild soapy water
Rinse the bath with distilled water
Add formaldehyde or quaternary ammonium germicide if algae or microorganisms are present
Chemical Usage Precautions
Ensure the following chemicals are never used
Limit the use of necessary chemicals to a maximum of four hours
Removing Discoloration
Wear heavy gloves and goggles for protection
CPU Or Display/Keyboard Board Replacement
Board Removal
Remove connectors from CPU board
Remove connector J102 from power supply board with care to avoid bending pins
Remove four nuts from CPU board and remove CPU board and Keyboard/Display board
Remove J201 from CPU board with care to avoid bending pins
Remove board
Board Installation
Install new CPU board and Keyboard/Display board by reversing removal procedure
Software Configuration
Power Supply Board Replacement
Connector Removal
Remove connectors from board
Ensure J102 connector pins are not bent
Board Removal
Remove nuts from board
Remove the power supply board
New Board Installation
Install new power supply board
Reconnect connectors to board
Heater Replacement
Heater Removal
Remove nuts and disconnect wires
Remove two hex nuts from heater ends using a 13/16" socket
Remove heater
Heater Installation
Install new heater
Reconnect wires and secure nuts
Post Installation Check
Is the heater securely installed?
Parts for Thermo Fisher Circulating Water Bath 2865
Access the parts list for your equipment in MaintainX.
Quaternary Ammonium Germicide
3166250
Power Supply Pcb Assembly
3176677
Quaternary Ammonium Germicide
3166250
Power Supply Pcb Assembly
3176677
Quaternary Ammonium Germicide
3166250
Power Supply Pcb Assembly
3176677
