TGW Narrow Belt Sorter NBS 30

Residue or build up of fibers between UHMW track at joints removed

Residue or build up on carrier rollers removed

Residue or buildup on encoder wheels removed

Sign off on the Narrow Belt Sorter Service

Lubricate unsealed bearings in rollers with light oil if dry sounding. Check free spin of rollers

Drain and flush gearcase after each 2,500 hours of normal operation or at least every 6 months (if applicable)

Inspect and clean motor control centers

Inspect bearings, gear reducers and motors for excessive noise or heat

Clean breather cap on gear motor (if used)

Check operation of all electrical controls

Check for proper PSI on air regulators

Replace missing or excessively worn tires

Remove any residue or fiber that has built up in drive groove of divert wheels

Check to see if all orings for driving divert wheels are in place. Replace all missing or worn orings

Check to see if belt is tracked correctly thru lower belt guide wheels. Examine guide wheels for wear. Replace any wheels that are excessively worn

Examine divert snubbers, and drive rollers for residue build up. Clean off any residue

Check to see that all wheel brackets are tight. Replace any missing hardware, and tighten any loose hardware

Sign off on the divert assembly maintenance

Examine drive pulley for excessive lagging wear

Remove any residue built up on drive pulley

Check to see if belt is tracked correctly thru lower belt guide wheels

Examine guide wheels for wear. Replace any wheels that are excessively worn

Examine belt guide feeder rollers. Remove any residue built up on rollers

Examine individual take up wheels for wear. Clean off any build up on wheels

Examine take up snubber pulleys. Clean off any residue built up on pulleys

Check chain tension. An over tensioned chain will cause excessive gearbox noise

Sign off on the drive assembly maintenance
