Terex Site Dumper TA300

Transmission Drain oil and refill with new oil

Fuel Filter/Water Separator Renew

Transmission Breather Clean if required

Transmission Internal Strainer Clean

Drive shaft Bearings Check oil level. Add if low.

Inspect the machine as described in Section 4 of the operations manual

Visually check the engine for damage, loose or frayed belts and listen for any unusual noises

Change air cleaner element only when air restriction gauge locks up in the red

Inspect and remove any obstructions from the vacuator valve lips which should be open and pliable with the engine stopped

Articulation Pivot Nut - Check torque

Radiator Expansion Tank - Check coolant antifreeze

Engine Mounting Bolts - Check torque

Transmission Mounting Bolts - Check torque

Engine Air Cleaner - Clean / renew filter element

Engine - Check and adjust valve clearance

Axle Mounting Bolts - Check torque

Hydraulic Oil Tank - Drain oil, remove and clean filter screen assemblies. Reinstall filter screens and refill the tank

Wheel Planetaries Check oil level. Add if low

Differentials Check oil level. Add if low

Oscillation Pivot Check end float. Adjust if required.

Articulation Bearings Lubricate

Parking Brake Pads Check wear. Renew if required

Oil Can Points - Lubricate working parts with engine oil.

General Inspection - Check the entire machine for leaks, loose bolts and nuts or damaged parts. Examine the machine, particularly the chassis, for cracks or broken welds. Repair where necessary.

Engine Air Intake - Check the air intake system for wear points or damage to piping, loose clamps and leaks.

Engine Drain oil and refill with new oil

Battery Electrolyte Check level, Add Electro if low

Differentials - Check oil level and add if low.The correct oil level is up to the rim of the oil filler and level-check hole. Refer to relevant differential section within the maintenance manual for specific details.

Planetaries - Check oil level and add if low. Oil level should be at the lower bottom edge of the thread, with the wheel hub orientated so that the oil drain plugs are positioned horizontally in the middle of the axle. Refer to relevant planetary section within the maintenance manual for specific details.;
