Sullair Sullair Air-Cooled Compressor 10B 40HP-251334-004 AC 10B 40HP-251334-004 AC

The pipe ends are free of all deep scratches, gouges, dents, etc.

Install the retainer (1), gasket (2), and sleeve (3) on one side of the pipe as shown in Step 1

Install the remaining retainer (4) and gasket (5) on the other pipe end

Position the retainer (4) and gasket to proper pipe insertion depth (“D”)

Slide the sleeve (3) to the gasket (5) and move gasket (2) and retainer (1) into position as shown in Step 2. The pipe MUST be inserted to the proper depth (“D”) into both gaskets

Repair pressure regulator valve 250017-280, use repair kit 250019-453

Loosen the locknut and turn the adjusting screw counterclockwise until the inner spring tension is relieved. The adjusting screw should turn freely when the spring tension is relieved

Remove the spring chamber from the body to allow access to internal parts

Remove the spring button and the spring. The dampener will stay inside the spring as it is removed. Leave the dampener inside the spring as there is no need to remove it

After removing the spring, remove the gasket stop and brass gasket

Remove the pressure plate nut and disassemble the pressure plate, diaphragm, diaphragm gasket (rubberized asbestos), seat disc and seat gasket

Remove and discard the seat ring

Reassemble the regulator using the new parts provided in the repair kit

Reassemble the diaphragm, pressure plate, gasket, seat disc, and seat disc gasket and tighten the nut. All of these parts with the exception of the pressure plate are provided in the repair kit

Place a bright light inside the element to inspect for damage or leak holes. Concentrated light will shine through the element and disclose any holes

Inspect all gaskets and gasket contact surfaces of the housing. Should faulty gaskets be evident, correct the condition immediately

If the clean element is to be stored for later use, it must be stored in a clean container

After the element has been installed, inspect and tighten all air inlet connections prior to resuming operation

Sign off on the air filter element inspection

Replace the fluid filter element

Replace your fluid filter element and the gasket under any of the following conditions, whichever occur first

Conditions for replacing fluid filter element

To replace fluid filter element:

Using a strap wrench, remove the old element and gasket

Apply a light film of fluid to the new gasket

Hand tighten new element until new gasket is seated in the gasket groove

Clean exterior of air filter housing

Remove the air filter cover by loosening the wingnut securing the cover

Remove element and clean interior of housing using a damp cloth. DO NOT blow dirt out with compressed air

Reset the filter maintenance indicator

Sign off on the air filter element replacement
