Schneider Electric Schneider Electric Air Compressor Compact 150-6 W Oilfree Compact 150-6 W Oilfree
Create an account to install this asset package.
Maintenance Plans for Schneider Electric Schneider Electric Air Compressor Compact 150-6 W Oilfree Model Compact 150-6 W Oilfree
Integrate maintenance plans directly into your work orders in MaintainX.
Weekly Check
2.6.7 Check intake filter;
10 Hours Check
2.6.6 Checking the screw fittings
• Check that all the screw connections are secure, and retighten them if necessary.;
Yearly Maintenance
2.6.6 Checking the screw fittings
• Check that all the screw connections are secure, and retighten them if necessary.
2.6.8 Cleaning/replacing the check valve
1. Unscrew the locking screw (Figure 6a).
2. Clean insert, replace in case of damage, squeezing or hardening.
3. Clean seat, replace complete check valve if damaged.;
5 Yearly Replacement
2.6.9 Replacing the safety valve
1. Unscrew the safety valve (item 11) anticlockwise.
2. Apply medium-strength thread-locking fluid, e.g. Loctite® 243, to the thread of the new safety valve or wrap Teflon tape around the valve.
3. Tightly screw the new safety valve in clockwise.;
Parts for Schneider Electric Schneider Electric Air Compressor Compact 150-6 W Oilfree Compact 150-6 W Oilfree
Access the parts list for your equipment in MaintainX.
Electric motor
-
Compressor unit
-
Quick-action coupling (clean, regulated compressed air)
-
Safety valve
-
Pressure gauge (vessel pressure)
-
Electric motor
-
Compressor unit
-
Quick-action coupling (clean, regulated compressed air)
-
Safety valve
-
Pressure gauge (vessel pressure)
-
Electric motor
-
Compressor unit
-
Quick-action coupling (clean, regulated compressed air)
-
Safety valve
-
Pressure gauge (vessel pressure)
-
Unlock efficiency
with MaintainX CoPilot
MaintainX CoPilot is your expert colleague, on call 24/7, helping your team find the answers they need to keep equipment running.
