QED Environmental Systems Gas Analyzer GA 5000

Create an account to install this asset package.

Maintenance Plans for QED Environmental Systems Gas Analyzer Model GA 5000

Integrate maintenance plans directly into your work orders in MaintainX.

Gaz Analyzer Test

Warning: The self-test should only be done with the analyzer sampling fresh air.

General operation

Gas flow measurement

Calibration

Screen Backlight / Brightness

Battery charge level

Manufacturer’s service due date

The last gas check date

Software version programmed

Run this procedure

Gaz Analyzer Battery Maintenance

Warning: The battery charger is NOT covered by the Ex certification. The battery must be charged only in a safe area.

Note: To charge, the analyzer must be switched OFF before attaching the charger. Switching the analyzer on or off during charging will cancel the current charge. The analyzer should be left OFF during the charging cycle.

The instrument must be charged ONLY using the battery charger supplied with the instrument. The battery charger supplied is intended for indoor use only. Please ensure adequate ventilation while charging.

Note: Connect the charger to the mains attaching the appropriate adaptor. Contact LANDTEC for further information.

Note: This charger has been internally restricted to 1.5A

Enter the time taken for full charge

Enter the battery life after full charge

Enter the battery life after a quick 30 minute charge

Temperature can dramatically affect the battery life; please take this into account when estimating battery life. The unit should be switched-off while charging to give a complete and consistent charge. Turning off Bluetooth and dimming the contrast will increase battery life.

Run this procedure

Gaz Analyzer Check

Warning: Inhaling hydrogen sulphide gas (H2S) or other harmful gases can cause death. It is the responsibility of the user to ensure that he/she is adequately trained in the safety aspects of using H2S and other harmful gases. In particular, where hazardous gases are being used the gas exhausted from the analyzer must be piped to an area where it is safe to discharge the gas. Hazardous gas can also be expelled from the instrument when purging with clean air.

All necessary ID codes and information have been uploaded from GAM to the analyzer

Current date and time set on the instrument

The water trap filter is fitted and is clean and dry

Battery charge level

The channels have been zeroed, without gas concentration present

Check the span calibration with a known concentration calibration gas

Take readings

Sign off on the Gaz Analyzer Check

Run this procedure
