Piranha Ironworker P-90

Lubricate Upper Pull Arm On Side

Lubricate Lower Pull Arm On Side

Lubricate Upper Pull Arm Off Side

Lubricate Lower Pull Arm Off Side

Lubricate Upper Pull Arm Hinge Pin

Lubricate Coper Side Plate On Side (2 Places)

Lubricate Coper Side Plate Off Side (2 Places)

NOTE: The Selector Switch should be in the 'OFF' position while maintenance checks are being performed. Reference Page 12, Figure 'B'.

CAUTION: When the filter element is plugged, hydraulic fluid will by-pass the element, allowing contamination to enter the hydraulic system.

Is the Selector Switch in the 'OFF' position?

Is the hydraulic oil filter functioning properly?

Describe the workload and environmental conditions

Enter the number of hours of use

Upload a photo of the filter housing

Sign off on the hydraulic filter element change

Warning: This procedure requires trained personnel with PPE!

Enter the torque of socket head bolts and hinge pin jam nuts

All hydraulic hose and fitting connections are tight

Loctite hydraulic sealant or an equivalent product used on all connectors?

Hydraulic cylinder clevis is screwed tight on the piston rod

Sign off on the fasteners / connections check

Warning: This maintenance check requires trained personnel with PPE!

Is the dipstick indicator on the fill cap inside the access door?

Enter the fluid level as indicated by the dipstick

Was this checked as part of your normal maintenance cycle?

NOTE: We recommend that you implement a weekly maintenance program to inspect and lubricate your Piranha.

Upload a photo of the service record chart on Page RP-23

Sign off on the hydraulic oil level maintenance
