Panasonic Fan FV-08VRE2

1. Remove the trim ring by pulling down the mounting; springs. (Squeeze mounting spring and pull down carefully.); (Fig. 10)

2. Clean the trim ring. (Don’t put into hot water. Use; non-abrasive kitchen detergent, wipe dry with clean cloth.); (Fig. 11)

3. Dry the trim ring after cleaning.

4. Remove dust and dirt from fan body using a vacuum; cleaner. (Fig. 12)

5. Using a cloth dampened with kitchen detergent, remove; any dirt from fan body. Wipe dry with clean cloth. (Fig. 13)

6. Replace the trim ring. (Fig. 9);

1. Remove the trim ring by pulling down mounting springs.; (Squeeze mounting spring and pull down carefully.) (Fig. 10)

2. Remove the LED lamp. (Fig. 14)

3. Replace the 11 W BR30 shape LED lamp; (model:11BR30G4DIM/927/GU24, from the company Green; Creative). (Fig. 8 of page 6)

4. Replace the trim ring. (Fig. 9);
