Miller Engine Driven Welding Generator Big Blue 500D

Create an account to install this asset package.

Maintenance Plans for Miller Engine Driven Welding Generator Model Big Blue 500D

Integrate maintenance plans directly into your work orders in MaintainX.

1000 Hourly Engine Driven Welding Generator Maintenance

Change Oil

Change Oil Filter

Change Fuel Filter

Check Slip Rings

Clean Slip Rings

Check Brushes

Generator Brush

Mark and disconnect leads at brush holder cap. Remove brushes.

Are brushes damaged or at or near minimum length?

Run this procedure

8 Hourly Engine Driven Welding Generator Maintenance

Check Fuel/Water Separator

Check Fuel Level

Check Oil Level

Clean Oil, Fuel Spills

Run this procedure

250 Hourly Engine Driven Welding Generator Maintenance

Replace Unreadable Labels

Check Fan Belt Tension

Clean Cooling System

Check Spark Arrestor

Clean Spark Arrestor

1 Spark Arrestor Muffler

2 Clean out Plug

Remove plug and remove any dirt covering clean out hole.

Start engine and run at idle speed to blow out clean out hole. If nothing blows out of hole, briefly cover end of exhaust pipe with fireproof material.

Run this procedure

3000 Hourly Engine Driven Welding Generator Maintenance

Clean Injectors

6000 Hourly or 5 yearly maintenance:

Check Engine Timing Belt

Replace Engine Timing Belt

Run this procedure

100 Hourly Engine Driven Welding Generator Maintenance

Battery terminals cleaned

Air cleaner hoses checked

Air cleaner element checked

Primary element cleaned or replaced if dirty
