Karcher Floor Scrubber BR 75/75 W Classsic Bp

2. Pull out the brush replacement handle.

3. Remove the bearing cover including the squeegee blade.

5. Fit the new roller brush and centre it on the driver.

6. Install the bearing cover with the squeegee blade.

Note! Make sure the roller brush sits on the mounting mandrel and not underneath.

7. Pivot the brush replacement handle upwards and latch it into place.

8. Repeat the entire procedure at the other side.;

1. Press lock in the direction of the arrow and hold it there.

2. Pivot water distribution strip forward.

3. Pull out water distribution strip lengthways.

4. Clean the water distribution strip.

5. Fit water distribution strip back into the cleaning head and snap the lock into place.;

1. Open the waste water tank cover.

2. Pull the coarse dirt filter upwards and off.

3. Rinse off the coarse dirt filter under running water.

4. Reinsert the coarse dirt filter into the waste water tank.;

Risk of damage to the device due to improper cleaning.

Do not spray the device with water and do not use aggressive detergents.

• Rinse the waste water tank with clear water.

• Clean the exterior of the device using a damp cloth, wetted with a mild washing lye.

• Check the fluff filter and clean if required.

• Clean the coarse dirt filter.

2. Press the brush replacement pedal down, beyond the zone of resistance.

3. Pull the 1st disc brush sideways and out from underneath the cleaning head.

4. Hold the new disc brush under the cleaning head, then press upwards and latch it into position.

5. Repeat the procedure for the 2nd disc brush.;
