The John Deere Tractor 6105D is a robust agricultural machine designed for efficiency and reliability. This versatile tractor excels in various farming tasks, providing powerful performance and ease of maintenance for operators. Its advanced features ensure optimal productivity in the field.

Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant

PDF MANUAL

Manual for John Deere Tractor 6105D

MAINTENANCE RESOURCES

Complete asset maintenance, one click away

Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.

Documents & Manuals

Find all the essential guides in one place.

Tensioning Guide
Belt-diagram
C-120 pulleys
+ 13 more

Work Order Templates

Pre-built workflows to keep your asset running smoothly.

Daily Electrical System Inspection
Replace Roller and Pulley
Install Engine B-120
+ 29 more

Procedures

Integrate maintenance plans directly into your work orders.

Motion Industries
Applied Industrial Technologies
Electrical Brothers
+ 5 more

Parts

Access the parts list for your equipment in MaintainX.

Drive Motor
B2 Rollers
Tensioning System
+ 40 more

John Deere Tractor 6105D

Create an account to install this asset package.

Maintenance Plans for John Deere Tractor Model 6105D

Integrate maintenance plans directly into your work orders in MaintainX.

250 Hourly Tractor Maintenance

Inspect engine air intake filters

A dual element air cleaner is standard. A dirty primary element is indicated when air restriction indicator on instrument panel illuminates. A dirty element can result in loss of power or excessive smoke.

Clean primary element when indicator on instrument panel illuminates or every 250 hours.

Both elements should be replaced at the same time annually, regardless of condition.

1. Raise hood.

2. loosen latch (A) and remove cover (B).

3. Pull out primary filter element (A). Do not use excessive force. If filter does not pull out with ease, move side-to- side to remove safely.

4. Clean primary element by tapping on palm of your hand.

5. Check rubber seal around filter element for cracks and holes. Replace if element shows any imperfections.

Run this procedure

50 Hourly / Weekly Tractor Maintenance

Clean and check battery

1. Stop engine. (See procedure in Operating the Engine section.)

2. Remove battery cover. (See ACCESS BATTERY in this section.)

3. Wipe battery with a damp cloth. Clean and tighten connections, if needed.

4. Install cover and lower hood.

Check:

1. Use a battery hydrometer to check specific gravity of electrolyte in each cell. Charge battery if reading is below 1.215. Replace battery if difference between cells is morethan 0.050 or if battery will not charge above 1.225.

2. Always correct specific gravity reading for electrolyte temperature variation. Add 0.004 to the reading obtained in step one for every 10 °F above 80 °F (add 0.007 to the reading for every 10° above 27 C). Subtract at same rate if electrolyte temperature is below 80 °F (27 C). Correct specific gravity of a fully charged battery is 1.265 to 1.280.

3.A battery is considered fully charged when three consecutive hydrometer readings, taken at hourly intervals, show no rise in specific gravity.

Run this procedure

10 Hourly / 1 Daily Tractor Maintenance

Check engine oil level

Check coolant level

1. Raise hood.

2. Check level in coolant reservoir BEFORE starting tractor.

3. If engine is COOL and level is below MIN COLD mark, remove cap and add coolant to reservoir to bring level between MIN and MAX COLD mark.

4. Install cap and lower hood.

Drain water from fuel filters

1. Disconnect wiring harness (A).

2. Connect a small hoses to end of drains (B).
