John Deere Tractor 332

Install new filter and bleed the fuel system

Loosen hose clamp and pull steel tube from air cleaner

Remove dust from air cleaner by tapping the element with the palm of your hand, NOT ON A HARD SURFACE

Use compressed air under 30 psi (210 kPa) if necessary

Wash air cleaner in warm water and R36757 John Deere Filter Element Cleaner or an equivalent non- sudsing detergent for approximately 15 minutes if necessary

Rinse air cleaner from inside with clean water using a maximum water pressure of 40 psi (280 kPa)

Allow air cleaner to dry completely before using. Do not oven dry or use compressed air

Check Air restriction indicator

Signature of person completing maintenance

Check tire pressure with an accurate tire gauge

Keep tires at pressures shown below

Check Battery electrolyte level

To check electrolyte level: Lift hood, Remove battery caps, Electrolyte (A) should be 1/4 to 1/2 in. (6 to 12 mm) above plates (B), If necessary, add distilled water, Install caps, Lower hood.

Stop engine. Remove key. Apply moderate thumb pressure to belt halfway between pulleys. Belt should deflect approximately 1/2 in. (13 mm). To tighten belt, loosen adjusting nut. Apply pressure on rear of alternator housing. Tighten nut. Check belt tension again. Replace alternator belt if it is damaged. (See your John Deere dealer for this service.)

Check Tractor for loose hardware

Tighten hose clamps on air intake and cooling system hoses

Sign off on the 600 Hourly Maintenance
