JCB Compact Loadall 525-60

Extension ram piston rod pivot pin lubricated?

Secondary fuel filter replaced?

Axle mount security checked (condition)?

Body and Framework General Clean

Body and Framework General Check (condition)

1. Make sure that all of the guards and protective devices are in position, secured by their locking devices and free from damage.

2. Inspect all of the steelwork for damage. Include the following:

2.1. Examine all of the lifting point welds.

2.2. Examine all of the pivot point welds.

2.3. Examine the condition of all the pivot pins.

2.4. Check that the pivot pins are correctly in position and secured by their locking devices.

3. Check the steps and handrails are undamaged and correctly attached.

Body and Framework General Clean

Body and Framework General Check (condition)

1. Make sure that all of the guards and protective devices are in position, secured by their locking devices and free from damage.

2. Inspect all of the steelwork for damage. Include the following:

2.1. Examine all of the lifting point welds.

2.2. Examine all of the pivot point welds.

2.3. Examine the condition of all the pivot pins.

2.4. Check that the pivot pins are correctly in position and secured by their locking devices.

3. Check the steps and handrails are undamaged and correctly attached.

Hydraulic tank oil filters replaced

Hydraulic tow hitch inner leg (if installed) Lubricate

Hydraulic towhitch pivot pin (if installed) Lubricate

Boom wear pad runways Check (condition)

Boom wear pad clearance Check (condition)

Boom wear pad condition and security (replace if required) Check (condition)

Cab heater fresh air filter (if installed) Change

Notice: Do not exceed the correct level of engine oil in the sump. If there is too much engine oil, the excess must be drained to the correct level. An excess of engine oil could cause the engine speed to increase rapidly without control.
