Hyster-Yale Lift Truck ERP030VTN36TE084

Warning: This procedure requires trained personnel with PPE!

Drive tire removed and lift truck frame blocked?

Breather cap removed with a flat screwdriver?

Spring removed by hand and breather ball forced out with compressed air?

6mm thread tap installed into breather using a tap wrench and breather pulled out of housing?

New breather positioned into housing by hand?

Breather driven into housing using Breather Set Tool and a nylon faced hammer?

Drive tire reinstalled and lugs tightened to 170 Nm? Lift truck removed from blocks?

Sign off on the transaxle breather repair

Safety: Block the truck frame and wheels to prevent unexpected movement

Transaxle positioned at the same height and position as with drive tire installed

Key switch turned to OFF position

Drip pan with at least a 3.0 liter (3.3 qt) capacity placed under transaxle

Breather inspected for proper operation

Warning: This procedure should be performed by a trained technician

Transaxle removed from lift truck

Parking brake and traction motor removed from transaxle

Amount of oil drained from transaxle

Snap ring in brake cylinder removed

Pressurized air directed into service brake line port in cover

Spring recovered from beneath cap

Drive tire removed and lift truck frame blocked

Damaged stud removed using adjustable grip pliers

Thread tap (size M14 x 1.5) run into stud hole to clean and repair any damaged threads

Threads tested with a thread plug gauge (size M14 x1.5 - 6H)

If threads are within specification, new stud installed using Stud Installation Tool

Tighten studs to 80 Nem (59 Ibf ft)

Drive tire reinstalled and lugs tightened to 170Nm

Sign off on the transaxle stud repair

Remove hood and seat. See Hood and Seat Assembly section in this manual

Remove rear capscrew, washers, and vibration mount top from rear leg and counterweight

Repeat Step 2 for opposite rear leg

Remove three capscrews from cowl and front leg

Repeat above step for opposite front leg

Remove nut, washers, front capscrew, and vibration mount top from front leg and frame

Repeat above step for opposite front leg

Use a lifting device to lift overhead guard until it is just higher than the counterweight

Tag and disconnect electrical wiring for display. Remove display from display cover
