Maintenance Plans for Hobart Hobart - Handler 210 Model Handler 210

Integrate maintenance plans directly into your work orders in MaintainX.

Changing Drive Roll Or Wire Inlet Guide

Check mark

Turn off welding power source.

Check mark

1. Inlet Wire Guide Securing Screw

Check mark

2 Inlet Wire Guide

Check mark

Loosen screw. Slide tip as close to drive rolls as possible without touching. Tighten screw.

Check mark

3 Retaining Pin

Check mark

To remove drive roll, push drive roll in and rotate it (1/4 turn) to the open slot and slide it out over the retaining pin.: To secure drive roll, locate open slot and push drive roll completely over retaining pin, then rotate drive roll (1/4 turn) to closed slot.

Check mark

4 Drive Roll

Check mark

The drive roll consists of two different sized grooves. The stamped markings on the end surface of the drive roll refers to the groove on the opposite side of the drive roll. The groove closest to the motor shaft is the proper groove to thread (see Section 5-12).;

Run this procedureArrow right

3 Months Check

Check mark

1. Replace unreadable labels.

Check mark

2. Clean weld terminals.

Check mark

3. Replace damaged gas hose.

Check mark

4. Check and replace cords if necessary.

Check mark

5. Check and replace gun cables if necessary.

Check mark

6. Check and replace weld cables if necessary.

Run this procedureArrow right

6 Months Job

Check mark

1. Clean drive rolls.

Check mark

2. Clean inside unit.;

Run this procedureArrow right

Drive Motor Protection

Check mark

Drive motor protection circuit protects drive motor from overload. If drive motor becomes inoperative, release gun trigger and wait until protection circuit resets allowing drive motor to feed wire again.;

Run this procedureArrow right

Overload Protection

Check mark

Supplementary Protector - CB1

Check mark

CB1 protects unit from overload. If CB1 opens, unit shuts down.

Check mark

Reset supplementary protector;

Run this procedureArrow right

Parts for Hobart Hobart - Handler 210 Handler 210

Access the parts list for your equipment in MaintainX.

Part Name
Part Number

Base, Lower

228 645

Door, Access

199 566

Cable Tie

197 198

Blade, Fan Cooling

409 953-001

Capacitor, Electrlit

226 191

Base, Lower

228 645

Door, Access

199 566

Cable Tie

197 198

Blade, Fan Cooling

409 953-001

Capacitor, Electrlit

226 191

Base, Lower

228 645

Door, Access

199 566

Cable Tie

197 198

Blade, Fan Cooling

409 953-001

Capacitor, Electrlit

226 191
