Genie Articulated Boom Lift S80

Drive hub specifications require that this procedure be performed after the first 50 hours of operation

After the initial oil replacement, specifications require that this procedure be performed every 1000 hours

Replacing the drive hub oil is essential for good machine performance and service life. Failure to replace the drive hub oil may cause the machine to perform poorly and continued use may cause component damage

1. Select the drive hub to be serviced. Drive the machine until one of the two plugs is at the lowest point

2. Remove the plugs and drain the oil into a suitable container

3. Drive the machine until one of the two plugs is at the highest point

4. Drive hubs with 2 plugs: Fill the hub until the oil level is even with the bottom of the lowest plug hole. Refer to Specifications, Hydraulic Specifications

Required maintenance procedures and additional engine information are available in the manufacturer's manuals. Refer to Specifications, Engine Operator and Maintenance Manuals

Clean/Adjust/Replace Spark plugs

Tighten/Replace Loose or missing fasteners

Check oil, fuel, and coolant systems for leaks

Clean/replace air cleaner element

Check for leaks Oil, fuel and coolant systems

Clean/replace air cleaner element

Check electrical wiring for chafing or damage
