Farris Engineering Valve 27ET25E-M71/N1

Farris Engineering Valve 27ET25E-M71/N1

Create an account to install this asset package.

Maintenance Plans for Farris Engineering Valve Model 27ET25E-M71/N1

Integrate maintenance plans directly into your work orders in MaintainX.

Valve Backpressure Test

Check mark

Valve Eligibility Check

Check mark

Verify valve type for backpressure test

Check mark

Is the valve an open lever valve or does it have an exposed spring?

Check mark

Backpressure Testing

Check mark

Enter the inlet size of the valve (in inches)

Check mark

Does the valve exceed 1" inlet size?

Check mark

Enter the test pressure used (must be at least 30 psi)

Check mark

Use a suitable leak detection solution to verify tightness of all gasket joints and vent/drain plugs

Check mark

Leakage Detection and Rework

Run this procedureArrow right

Valve Set Pressure Testing

Check mark

Set Pressure Test

Check mark

Use appropriate test fluid as shown in Table 2

Check mark

Mount valve on test stand and note set pressure and CDTP

Check mark

Hold stem tightly and tighten spring adjusting screw clockwise

Check mark

Slowly raise test drum pressure and observe opening (set) pressure

Check mark

Is the set pressure within +/-3% tolerance?

Check mark

Reduce test drum pressure 25% below opening pressure if necessary

Check mark

Adjust spring adjusting screw if necessary

Check mark

Lock the jam nut in place

Run this procedureArrow right

Valve Seat Leakage Test

Check mark

Preparation

Check mark

Mount the valve on the test stand

Check mark

Attach a blind test fixture for air, gas & vapor service valves

Check mark

Pressure Setup

Check mark

Enter the cold differential test pressure (CDTP)

Check mark

Select the CDTP range

Check mark

Enter the test pressure to be held

Check mark

Leakage Test for Air, Gas & Vapor Service Valves

Check mark

Select the valve inlet size

Run this procedureArrow right

Valve Lifting Lever Assembly

Check mark

Open Lifting Lever (Figure 1.5)

Check mark

Remove wire seal and slide out button head rivet, releasing lever from cap.

Check mark

Pull lever free of cap.

Check mark

Remove set screw from base of cap and lift cap off bonnet.

Check mark

Hold the stem with pliers (wrap the jaws to avoid marring), remove stem jam nut and stem test washer.

Check mark

Clean all parts.

Check mark

Reassemble in reverse order.

Check mark

Packed Lifting Lever (Figure 1.6)

Check mark

Remove groove pin from lever and slide lever off the cam.

Run this procedureArrow right

Valve Disassembly

Check mark

Preparation

Check mark

Place the valve at a suitable height on a clean and strong work surface.

Check mark

Mount valve vertically in a vise using the flats on the valve body.

Check mark

Cap and Gasket Removal

Check mark

Remove wire seal.

Check mark

Unscrew cap by turning counter-clockwise.

Check mark

Remove the cap gasket.

Check mark

Spring Adjusting Screw Removal

Check mark

Hold the spring adjusting screw with a smooth jaw wrench and remove the jam nut.

Run this procedureArrow right

Parts for Farris Engineering Valve 27ET25E-M71/N1

Access the parts list for your equipment in MaintainX.

Part Name
Part Number

Lapping Compound 3F

18632X1(055)

Lapping Compound 38-500

18633X1(075)

Lapping Compound 38-1200

18634X1(105)

Pyrex Lapping Plate 1

7688

Pyrex Lapping Plate 2

7689

Lapping Compound 3F

18632X1(055)

Lapping Compound 38-500

18633X1(075)

Lapping Compound 38-1200

18634X1(105)

Pyrex Lapping Plate 1

7688

Pyrex Lapping Plate 2

7689

Lapping Compound 3F

18632X1(055)

Lapping Compound 38-500

18633X1(075)

Lapping Compound 38-1200

18634X1(105)

Pyrex Lapping Plate 1

7688

Pyrex Lapping Plate 2
