Maintenance Plans for Eppendorf Freezer Model C760

Integrate maintenance plans directly into your work orders in MaintainX.

Electrical Components Maintenance

Check mark

NOTICE! Risk of material damage

Check mark

• Maintenance, adjustment and repair work should be carried out only by QUALIFIED, EXPERIENCED personnel who have been AUTHORIZED to undertake such work by Eppendorf or its authorized agents.

Check mark

• Failure to use authorized service agents will invalidate the warranty.

Check mark

7.2.5 Electrical components

Check mark

WARNING! Risk of personal injury

Check mark

• During routine maintenance, care must be taken to avoid any damage to the gaskets and sealing grommets of these enclosures; also check the gaskets and sealing grommets routinely to ensure their integrity.

Check mark

Should any damage or deformity be detected, the gasket and/or sealing grommet must be replaced immediately.

Check mark

• Failure to observe this safety warning will invalidate the warranty and could result in a dangerous situation.

Check mark

7.2.5.1 Lamps

Run this procedureArrow right

Freezer Defrosting

Check mark

NOTICE! Risk of material damage. Maintenance, adjustment and repair work should be carried out only by QUALIFIED, EXPERIENCED personnel who have been AUTHORIZED to undertake such work by Eppendorf or its authorized agents. Failure to use authorized service agents will invalidate the warranty.

Check mark

NOTICE! Risk of material damage. Do not attempt to chip or scrape the ice with a sharp instrument. Allow the ice to melt naturally.

Check mark

De-activate the alarm by switching the battery (alarm) switch (located behind the lockable panel on the front of the freezer) to off (0).

Check mark

Unplug the freezer from the mains/electrical supply.

Check mark

Leave the inner and outer doors or lids open.

Check mark

Allow the accumulated ice to melt.

Check mark

Mop up the resulting water.

Check mark

Dry and decontaminate the interior of the freezer.

Check mark

When defrosting is complete, reconnect the freezer to the mains/electrical supply.

Run this procedureArrow right

1 Monthly Door or Lid Seal Cleaning

Check mark

NOTICE! Risk of material damage

Check mark

Maintenance, adjustment and repair work should be carried out only by QUALIFIED, EXPERIENCED personnel who have been AUTHORIZED to undertake such work by Eppendorf or its authorized agents.

Check mark

Failure to use authorized service agents will invalidate the warranty.

Check mark

7.1.5 Door or lid seal

Check mark

Be sure to treat the door or lid seal with care. Avoid damaging this seal in any way. The freezer cannot operate properly with a defective seal.

Check mark

It is advisable to wipe both the seal and the surface against which it seals with a soft dry cloth once a month.

Check mark

Seal and surface against which it seals wiped with a soft dry cloth

Check mark

Sign off on the door or lid seal cleaning

Run this procedureArrow right

3 Monthly Grille Cleaning

Check mark

NOTICE! Risk of material damage

Check mark

Maintenance, adjustment and repair work should be carried out only by QUALIFIED, EXPERIENCED personnel who have been AUTHORIZED to undertake such work by Eppendorf or its authorized agents.

Check mark

Failure to use authorized service agents will invalidate the warranty.

Check mark

Serious damage to the freezer may result if the air intake is blocked. Check that there is no obstruction of the airflow to the freezer. The air intake filter must also be cleaned regularly.

Check mark

Air intake unblocked?

Check mark

Filter cleaned regularly?

Check mark

Remove the filter from behind the grille by turning the thumbscrews ¼ turn and opening grille downward. The filter should be washed in warm soapy water and left to air dry before replacing.

Check mark

Filter removed and cleaned?

Check mark

The air intake grille must be cleaned regularly to keep it free from dust and debris. Under normal conditions, clean the grille once every three months. If the area around the freezer is very dusty or dirty, clean the grille more often.

Run this procedureArrow right

Freezer Cleaning

Check mark

7.1 Cleaning

Check mark

NOTICE! Risk of material damage

Check mark

• Maintenance, adjustment and repair work should be carried out only by QUALIFIED, EXPERIENCED personnel who have been AUTHORIZED to undertake such work by Eppendorf or its authorized agents.

Check mark

• Failure to use authorized service agents will invalidate the warranty.

Check mark

7.1.1 Painted surfaces

Check mark

All exterior paint work and inner doors should be cleaned using a solution of mild detergent in water. Do not use abrasive cleaners or solvents.

Check mark

7.1.2 Interior and shelves

Check mark

The interior panels and shelves are made of stainless steel. They may be cleaned using a recommended cleaning solvent, 70 % Isopropyl alcohol 30 % distilled water applied with a lint free cloth.;

Run this procedureArrow right

Parts for Eppendorf Freezer C760

Access the parts list for your equipment in MaintainX.

Part Name
Part Number

U101 Upright Freezer, 115 V

U9420-0000

U101 Upright Freezer, 208 - 230 V

U9420-0002

U101 Upright Freezer, 230 V

U9420-0001

U535 Upright Freezer, 115 V

U9430-0000

U535 Upright Freezer, 208 - 230 V

U9430-0002

U101 Upright Freezer, 115 V

U9420-0000

U101 Upright Freezer, 208 - 230 V

U9420-0002

U101 Upright Freezer, 230 V

U9420-0001

U535 Upright Freezer, 115 V

U9430-0000

U535 Upright Freezer, 208 - 230 V

U9430-0002

U101 Upright Freezer, 115 V

U9420-0000

U101 Upright Freezer, 208 - 230 V

U9420-0002

U101 Upright Freezer, 230 V

U9420-0001

U535 Upright Freezer, 115 V

U9430-0000

U535 Upright Freezer, 208 - 230 V

U9430-0002
