Eaton Variable Frequency Drive DH1-347D6DN-C54C
Create an account to install this asset package.
Maintenance Plans for Eaton Variable Frequency Drive Model DH1-347D6DN-C54C
Integrate maintenance plans directly into your work orders in MaintainX.
Variable Frequency Drive Regularly Maintenance
Is the PowerXL frequency inverter damaged by external influences?
If the PowerXL frequency inverter is damaged, contact Technical Service.
Are the cooling vents clean?
Are the tightening torques of the terminals checked?
Charging the Internal DC Link Capacitors
After extended storage times or extended downtimes during which no power is supplied (>12 months), the capacitors in the internal DC link must be recharged in a controlled manner in order to prevent damage.
To do this, the PowerXL variable frequency drive must be supplied with power, with a controlled DC power supply unit, via two mains DC bus connection terminals.
Please consult the factory for detailed instructions.
Sign off on the Variable Frequency Drive Regularly Maintenance
6 Monthly Variable Frequency Drive Maintenance
Check the fan function
Filter in the switching cabinet doors (see manufacturer specifications)
Check connection terminals for corrosion
Check all metallic surfaces for corrosion
Parts for Eaton Variable Frequency Drive DH1-347D6DN-C54C
Access the parts list for your equipment in MaintainX.
Type 12/IP54 Kit
DXH-ACC-4FR1N12KIT
Main Control Board
DXH-SPR-CTRLBOARD
UL Conduit Plate
DXG-SPR-FR1CPUL
Middle Chassis Cover
DXG-SPR-FR1MCC
Standard Keypad
DXH-KEY-LCD
Type 12/IP54 Kit
DXH-ACC-4FR1N12KIT
Main Control Board
DXH-SPR-CTRLBOARD
UL Conduit Plate
DXG-SPR-FR1CPUL
Middle Chassis Cover
DXG-SPR-FR1MCC
Standard Keypad
DXH-KEY-LCD
Type 12/IP54 Kit
DXH-ACC-4FR1N12KIT
Main Control Board
DXH-SPR-CTRLBOARD
UL Conduit Plate
DXG-SPR-FR1CPUL
Middle Chassis Cover
DXG-SPR-FR1MCC
Standard Keypad
DXH-KEY-LCD
