Daikin Cooling-Only Outdoor Unit RKM35QVMA

Has it been 10 minutes since turning off all power supplies?

Detach the fastener and pull out the sound blanket (outer)

Pull out the sound blanket (inner)

Wait for 10 minutes or more after turning off all power supplies before disassembling work.

Ensure proper ventilation if refrigerant gas leaks during work.

Prepare wet cloth to extinguish fire immediately in case refrigerant oil catches fire.

Collect all refrigerant gas to avoid discharging it into the atmosphere.

Ensure refrigerant gas is empty in the circuit.

Apply nitrogen replacement when heating up the brazed part.

Provide a protective sheet or steel plate to protect peripheries from brazing flame.

Wait for 10 minutes after turning off all power supplies before starting disassembly.

Ensure pipes and parts heated by the gas brazing machine are cool to avoid burns.

Is the room ventilated in case of refrigerant gas leakage?

Collect all refrigerant gas to prevent atmospheric discharge.

Ensure refrigerant gas is empty in the circuit.

Apply nitrogen replacement when heating brazed parts.

Avoid using a metal saw for cutting pipes.

Warning: Wait for 10 minutes or more after turning off all power supplies before disassembling work.

Remove the 4 screws from the top panel

Remove the 5 screws from the front panel

Lift up the left side of the front panel and unfasten the 3 hooks

Unfasten the 2 right side hooks

Warning: Wait for 10 minutes after turning off all power supplies before disassembling work.

Remove the screws of the partition plate

Lift up the partition plate and remove it

Fit the hook on the bottom frame when reassembling

Remove the electronic expansion valve coil
