Cincinnati Hydraulic Press Brake 90 CBII x 6 FT.

Need answers fast?
Explore the manual using AI.

Cincinnati Hydraulic Press Brake 90 CBII x 6 FT.
Cincinnati Hydraulic Press Brake 90 CBII x 6 FT.

Turn manuals into instant answers
with your AI-powered assistant
Turn manuals into instant answers
with your AI-powered assistant

PDF MANUAL

Manual for Cincinnati Hydraulic Press Brake 90 CBII x 6 FT.

MAINTENANCE RESOURCES

Complete asset maintenance, one click away

Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.

Documents

Documents & Manuals

Find all the essential guides in one place.

  • CheckTensioning Guide

  • CheckBelt-diagram

  • CheckC-120 pulleys

  • + 13 more

Work Orders

Work Order Templates

Pre-built workflows to keep your asset running smoothly.

  • CheckDaily Electrical System Inspection

  • CheckReplace Roller and Pulley

  • CheckInstall Engine B-120

  • + 29 more

Procedures

Procedures

Integrate maintenance plans directly into your work orders.

  • CheckMotion Industries

  • CheckApplied Industrial Technologies

  • CheckElectrical Brothers

  • + 5 more

Parts

Parts

Access the parts list for your equipment in MaintainX.

  • CheckDrive Motor

  • CheckB2 Rollers

  • CheckTensioning System

  • + 40 more

Cincinnati Hydraulic Press Brake 90 CBII x 6 FT.

Cincinnati Hydraulic Press Brake 90 CBII x 6 FT.

Create an account to install this asset package.

Maintenance Plans for Cincinnati Hydraulic Press Brake Model 90 CBII x 6 FT.

Integrate maintenance plans directly into your work orders in MaintainX.

Piston Rod Seal Replacement

Check mark

Run ram to the maximum down position and block both ends of the ram

Check mark

Turn OFF machine and LOCK the electrical disconnect

Check mark

Remove ram pin cover plate on front of ram using extractor bar

Check mark

Swing cylinder out from ram and insert wooden block between cylinder and housing so piston rod is clear of ram

Check mark

Remove 6 or 8 bolts from seal retainer and insert 3 or 4 3/8\ x 1\" (or longer) set screws into tapped holes in retainer. Tighten set screws to back-off retainer"

Check mark

Support retainer to keep from falling free and remove seal retainer

Check mark

Remove seal from groove in bore of seal retainer. The seal has an energizing \o\" ring to pre-load the seal"

Check mark

Replace with a new seal. Also inspect non-metallic bearing strip in bore of seal retainer and \o\" ring seal in top face of retainer. Replace if necessary"

Check mark

Using auto body slide hammer-puller, remove the piston rod seal. This seal has no energizing. Be careful not to damage finished surface of piston rod or lower head seat

Run this procedureArrow right

1 Yearly Air Breather Cleaning

Check mark

Cap removed and back blow performed

Check mark

Low pressure air hose used for back blow

Check mark

Air breather cleaned

Check mark

Enter the current operating hours

Check mark

Suction strainer replaced if operating hours are more than 1000 or it's been 6 months

Check mark

Filter cartridge replaced if operating hours are more than 1000

Check mark

Sign off on the air breather cleaning

Run this procedureArrow right

Bed and Ram Level Check

Check mark

Set tilt control adjusting knob and pointer to their 'zero' positions

Check mark

Adjust the speed control cams so the ram approaches the bottom of the stroke in low speed

Check mark

Mount a dial indicator on the extreme right end of the bed so it indicates the bottom reversal point of the ram

Check mark

Verify that the ram is reversing consistently to the same indicator setting

Check mark

Without changing the indicator or bottom stroke stop setting, reposition the dial indicator at the extreme left end of the bed

Check mark

Run a number of strokes, adjusting the tilt control knob to raise or lower the left end of the ram, until the indicator reads the same as it had at the right end of the machine

Check mark

Repeat Steps 4, 5 and 6 until both ends of machine have the same indicator reading at the ram reversal point

Check mark

If necessary, replace the tilt adjusting knob graduated decal aligning its zero position. Also adjust the tilt pointer to its zero position

Check mark

Sign off on the bed and ram level check

Run this procedureArrow right

1 Monthly Hydraulic Press Brake Maintenance

Check mark

Lubricate cylinder clevis pin(s)

Check mark

Clean and flush ram guides with oil

Check mark

Check for water in reservoir(s)

Check mark

Wipe entire machine clean

Check mark

Check leveling system

Check mark

Check reservoir oil level(s) everyday

Check mark

Check lubrication at both guides everyday

Check mark

Clean leveling band every 1 week

Check mark

Lubricate stroke adjustment and tilt adjustment screws every 1 week

Run this procedureArrow right

3 Monthly Hydraulic Press Brake Maintenance

Check mark

Check machine levelness

Check mark

Check ram guide clearances – relevel if necessary

Check mark

Adjust swivel end guide bearings

Run this procedureArrow right

Parts for Cincinnati Hydraulic Press Brake 90 CBII x 6 FT.

Access the parts list for your equipment in MaintainX.

Part Name
Part Number

C.I Grease

H-2M

C.I Oil

B-150

C.I Grease

H-2M

C.I Oil

B-150

C.I Grease

H-2M

C.I Oil

B-150
